P5-16s SMD Indoor 320X160 RGB P5 LED Module Indoor LED Display

P4 mm competitive price slim led module

1. Our Service

1)Your inquiry related to our products or price will be replied in 24hrs

2)OEM&ODM, any your customized lightings we can help you to design and put into product

3)Distributoership are offered for your unique design and some our current models

4)Protection of your sales area, ideas of design and all your private information

5)Top Quality+Reasonable Price+Responsible After Service=Successful & Win

2. Trade Terms

1. Payment: T/T, 30% deposits before production, 70% balance to be paid before dleiverying

2. Shipping freight are quoted under your requests

3. Shipping port: ShenZhen, Mainland China


Specifications:
1)Excellent Quality,Pass ISO9001:2000
2)Low Power Consumption. High brightness
3)Long working hours, Long durability
4)Good Uniformity, High performance
5) Competitive price, Timely delivery

  smd indoor 320x160 rgb p5 led module

Product Description

1. 320x160 rgb p5 led module parameter :


320x160 rgb p5 led module indoor led screen module
Item	Parameter	Unit
Pixel Pitch	5	mm
Resolution of Module	64×32	dots
Module Size	320×160	mm
Module Weight	0.24	kg
Pixel Configuration	SMD2121 1R1G1B
drive method	high refresh rate
Pixel Density	40,000	dots/sqm
Brightness (White Balance)	≥1300	nits(cd/sq.m)
Red Wavelength	620-625	nm
Green Wavelength	520-525	nm
Blue Wavelength	470-475	nm
Scan Mode	1/16 Scan or 1/8 Scan optional
Viewing Distance	3--35	M
Best View Distance	5--15	M
Viewing Angle-Horizontal	120	deg.
Viewing Angle-Vertical	120	deg.
Module Maximum Power	25	W
Max. Power Consumption	6,00	W/sq.m
Avg. Power Consumption	300	W/sq.m
Working Voltage	5V 40A
Power Supply	AC 110/220V
Refresh Rate	1,000	Hz/S
Frame Rate	≥ 60	Hz/S
Gray Scale	4096 grades gray
Display Color	256*256*256
Display Function	Text,news,advertising,flash,animation
Input Signal	RF,S-Video,RGB,RGBHV,YUV,YC,SDI,HD-SDI,DVI,UXGA,COMPOSITION,etc.
Luminance Degradation	Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature 25°C.
Defective Dot Rate	<0.0001
Life Span	100,000	hours
MTBF	>5,000	hours
Storage Temperature	45	°C
Working Temperature	-20 -- +60	°C
Working Humidity	10-90%RH
Control System	Synchronization or Asynchronization
Quality Certificate	ECE,RoHS,TUV,ISO9001:2008
Warrenty	2 Years
Working Environment	Indoor


Advantages
320x160 rgb p5 led module advantage:
1) High refresh rate and high contrast which make the screen without any delay and smear phenomenon under direct sunlight.

2)Low electric current,high-bright lamps,equipped with PFC switching power supply that save 30% electricty.

3)Environment protection, antistatic, dust-proof, good heat dissipation, cost-effective .

4)Error detection and monitoring:it can monitor the inner temperature,voltage,cooling fans etc and error detection automatically.

5) High reliability: using distributed scanning technology and module design technology that make higher reliability and stability.

6) Steady and reliable system:with strong anti-interference ability and long service life that can continually work for over 24 hours, and it's easy to operate the system.
