| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Square Meter |
| Pay Type: | T/T,Western Union |
| LED Specification | ||
| 1 | LED Chip Brand | Red: Opto / Epistar Green & Yellow: Silan |
| 2 | Wave Length (nm) | R: 625nm; G: 525nm; B: 470nm |
| 3 | Pixel Configuration | SMD 3 in 1 |
| Module & Cabinet Specification | ||
| 4 | Physics Distance Between Pixels | 4 mm |
| 5 | Physics Pixel Density | 62, 500Pixel/m² |
| 6 | Module Dimensions (W x H) | 128mmX 128mm |
| 7 | Physics Pixel / Module | 32 x 32 = 1024 |
| 8 | Cabinet Dimensions ( W x H xT) | 640mm X 640mm X 160mm |
| 9 | Physics Pixel / Cabinet | 160 x 160 = 25, 600 |
| 10 | Cabinet Weight | 20 kg |
| 11 | Cabinet Material | Steel Cabinet / Aluminum Cabinet |
| 12 | Cabinet Frame | Standard Frame Simple Frame (without backdoor) Lifting Frame (specially for rental use) |
| Screen Specification | ||
| 13 | Brightness | 2500cd/m² |
| 14 | Viewing Distance (min, max) | 2 - 300m |
| 15 | Power Consumption / Screen | MAX : 1200 w/m² ; Average: 300 w/m² ; |
| 16 | Drive Mode | 1/16 scan, constant current driving |
| 17 | Refresh Rate | 600 HZ |
| 18 | Frame Rate | 60HZ |
| 19 | Display Flatness | 0.5mm |
| 20 | Maintenance | Back maintenance, replace the module |
| 21 | Led Life Span | 100, 000 hours |
| 22 | Supply Voltage | AC220V/50HZ, ± 10%; AC110V/60HZ, ± 10% |
| 23 | Operating Temperature | -20º C~+50º C |
| 24 | Operating Humidity | 10%-90% |
| 25 | Storage Temperature | -40º C~+60º C |
| 26 | Viewing Angle | Horizontal: 120° ; Vertical: 65° |
| 27 | Grey Scale | Red, green, blue each 16k |
| 28 | Display Colors | 4096 Billion |
| 29 | IP Rating | IP20 no water proof, no dust proof |
| 30 | Aging Time in Factory | More than 72 hours constantly |
| Control | ||
| 31 | The Software | LED Studio |
| 32 | System Supported | Win 98 / 2000 / 2003 / XP / WIN7 |
| 33 | Control Mode | Real Time Control (Synchronous) |
| 34 | Display Capability | Flash, Video, Graphic, Text |
| 35 | Signal Supported | RGB, VGA, DVI, etc. |
| Prod Model: | P4mm |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Protection: | IP 20, No Water Proof, No Dust Proof |
| Compatibility: | PC, Video Processor, Camera, I-Pad, etc. |
| Control: | PC Control in Real Time |
| Power Input: | AC 220V/50Hz; AC 110V/60Hz, ± 10% |
| Pixel Configuration: | SMD 3 in 1 |
| Weight: | 60 Kg/M2 |
| Chip Brand: | Epistar / Opto & Silan |
| Signal Port: | Rj 45 |
| Resolution: | 62, 500 Pixels/M2 |
| FOB Port: | Shenzhen |
| Tube Chip Color: | Full Color |
| Display Function: | Video Display |
| Pixel Pitch: | 4mm |
| Pixel Configuration: | 1R,1G,1B |
| Scanning Mode: | 1/16 Scan |
| System Operating Platform: | WIN XP |
| Display Type: | LED Video Display |
| Application: | Shopping Guide |
| Pixel Density: | 62500 |
