P4 LED Video Display 4mm LED Display
| Price: |
US $ 568-588/Piece |
| Trade Terms: |
FOB,CFR,EXW |
| Min Order: |
1/Square Meter |
| Pay Type: |
L/C,T/T,Western Union |
DOT span(mm): 4
DOT color: Red green yellow
Module dots: 8*8
Module: Size(mm): 304*152
Module quantity: 8*4
Display dots: 64*32
Display color: Red yellow green
Display capacity: Maximum display resolution is 1280× 960, completely compatible with the windows operating deck, equivalent to the monitor of the computer.
Display character and application range: High color purity and brightness, uniform color, good consistency, can be used to display kinds of characters and graphs.
Aging test: ≥ 72hours
Best viewing distance: 2.0-20m
Viewing angle: 160 degrees
Working temperature: : (-20--60) degrees
Control mode: Dynamic scanning, VGA sync
Scanning frequency: ≥ 140Hz/s
Out of control DOT: No
Communication distance: ≤ 100m(twisted pair, no relay)
Working voltage: Mains supply(220V± 10%)
Maximum power consumption(w/m2): 800
Life span: ≥ 100000hours
| Screen Area | 8.064 m(W) × 3.072 m(H) = 24.772m² |
| Pixel density | 62,500 dots/m² |
| Screen Resolution | 2016 dots × 768 dots |
| Screen pixels | 1548,288 dots |
| Cabinet quantity | 27 pcs cabinets |
| Module quantity | 1512 pcs (56pcs/cabinet) |
| Brightness | >2000 nits (cd/m²) |
| Working Temperature | -20ºC ~ +60ºC |
| Operating Humidity | 10%~90% |
| Driving method | 1/16 scan, Constant Current |
| Viewing distance | > 5M |
| Working voltage | AC110/220V |
| Gray level | RGB/8192/14 bit |
| Refresh rate | > 800 Hz |
| Blind spot rate | < 0.00001 |
| Life-span | > 100,000 hours |
| Prod Model: |
BESD-IFP4-LDY09 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Sending Card: |
Linsnrv901 |
| Received Card: |
Linsnrv901 |
| Driving IC: |
5020 |
| Viewing Angle: |
40°/140° |
| Power Supply: |
AC110/220 ± 15% |
| Best View Distance: |
>3m |
| Display Type: |
LED Video Display |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Scanning Mode: |
1/16 Scan |
| Certification: |
CCC |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Pitch: |
4mm |
| Application: |
Shopping Guide |
| IP Rating: |
IP43 |
| System Operating Platform: |
WIN2000 |
| Pixel Density: |
62500DOT/M&Sup2 |
Xinhongxiang Optoelectronics (Shenzhen) Co., Ltd. As one of the most leading LED Products manufacturer in Shenzhen China, covering 10 000 square meters, register capital high up to 30 million CNY, is one high-tech enterprise focus on researching, producing, sale and service of LED products, . Nowadays Xinhongxiang owns fully automatic production lines, independent purifying workshop, researching center, most advanced production and inspection equipments, which guarantee the quality of the LED products. All the products have exported more than 100 countries, such as USA, Mexico, Canada, Brazil, Chile, Argentina, Panama, Colombia, Germany, France, Sweden, Italy, Spain, Russia, Poland, Turkey, Ukraine, South Africa, Egypt, Saudi Arabia, Singapore, Thailand, India etc
Developing History:
From 1996 to 2010, Xinhongxiang Optoelectronics (shenzhen) Co., Ltd, mainly involved in LED encapsulation and LED Display.
Since 2010, owe to enlarge the company scale and build up self-owned brand, Xinhongxiang focus on LED lighting, Shenzhen BESDLED Co., Ltd focus on LED display, business involved in indoor and outdoor LED Encapsulation, LED Display and LED Lighting Products.
LED Display:
Full Color Indoor and outdoor LED Display, single or dual basic color LED signs, LED Curtain, LED Dance Floor, Rental LED Display,
LED Lighting:
LED Bulb, LED Tube, LED Spotlight, LED DownLight, LED Panel Light, LED Street etc,
Comparing with many of LED Manufactures, xinhongxiang owns the following advantages to be your best choice for long term cooperation partner.
1, Fully automatic production lines
Xinhongxiang owns the entire LED manufacturing line, from original Semiconductor to LED chip, then assemble to LED display and LED lighting products.
2, Advanced production equipment
SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP LED, Spectrum and Color Separation Machine, LED oven, Wave solder, Reflow soldering, Spectrum electronic and color tester, temperature and humidity programmable tester, luminance meter etc. Are equipped for our LED Product production.
3, Many Certification approved to clear up the trade barriers
CE, FCC, UL, RoHS, CCC, ISO9001: 2000 etc are obtained.
4, Strong R&D Team
Xinghongxiang absorb many talents, with more than 500 staffs, and including more than 100 engineers and technician, which paves the way for R&D for new products and excellent sales service
5): After-Service,
Principles: Response in time, solve problem ASAP and ensure the use.
Period: During warranty period, free of all maintenance charges;
After Warranty, only charge the material cost.
All the life time, Technology support is free.
