P4 HD outdoor indoor 500*500mm portable LED display
Description:
This P4.8 can be used both indoor and outdoor .It is high definition LED rental display with slim and portable die-casting aluminum panel. 500*500mm , only 8 KG per panel. It's high resolution (43402 dots/m2) ; high brightness (>5000nits) ; Good waterproof (IP65 standard) ; It is very easy to calculate the size of LED screen .
Features:
1) Wide viewing angle by using SMD 3535 LED, it can reach 140 degree horizontally and vertically.
2) Ultra-thin and Super-light: only 7.8KG per cabinet of 500mmW*500mm . The depth is only 75mm, can stand on floor independently.
3) 500*1000mm cabinet can work with our 500*500mm die-casting aluminum cabinet so the height of LED screen can be both 1m and 0.5m
4) The appearance is very elegant,looks very high end
5) With fast lock system, it is easy to install and dismantle
6) It can be hung on truss or install on floor
7) The tolerance is less than 0.2mm so the gap between adjacent cabinet can be made to minimum.Surface is very flat,viewing angle is very wide.
8) High refresh rate with NOVA control system,no scaning line when take pictures.
9) It can save lots of labor cost,operating cost and transportation cost
10) High color, high gray scale , it shows very clear and vivid video / images.
11) It is very quiet because no fan installation
Please send an inquiry for more information., we will respond in 1 day !
Specifications:
Model | P4.81 HD outdoor indoor Die-casting rental LED display |
| Pixel pitch | 4.81mm |
| Pixel density | 43,264 dots /sqm |
| Module size(W*H) | 250 mm(width)*250 mm(height) |
| Module pixels(W*H) | 52 dots *52 dots |
| Pixel configuration | 1Red 1Green 1Blue |
| Drive mode | constant current driving 1/13 scan |
| LED lamp type | SMD2727 waterproof |
| Cabinet size(W*H*D) | 500mm*500mm |
| Color scale | 65,536 degree |
| View angle(H/V) | 140/120 degree |
| Brightness (White balance) | about 6000cd/sqm. |
| Power consumption(one cabinet) | Max: 200W / cabinet , Average: 100W / cabinet |
| Inputting Voltage | 90-264 VAC |
| Net weight | 7.5Kg / cabinet |
| Operating temperature | -30°C----+60°C |
| Operating humidity | 10%-95%RH |
| Life time | ≥100,000hours |
| MTBF | 5,000 hours |
| Whole Display Flatness | ≤0.5mm Juncture |
| Frame frequency | 25-60 Hz/s |
| Refresh rate | ≥2,000Hz /s |
| Control distance |
100m (without repeater), single mode fiber:20km,
multi mode fiber: 500m |
LED control system | LINSN,Dbstar,Nova-star,ZDEC,Colorlight is selectable |
| Operating system |
Windows 2000 / Windows Xp / Windows 7 / windows 8 /8.1 /
windows 10 |
Protection grade | IP65 |
| Maintenance way | Rear Access |
| Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI |
ENBON optoelectronics Limited is a High-tech enterprise specialized in R&D, manufacturing and sales of outdoor & indoor LED display. It was established in Jan 15, 2010 covering an area of 1 building with around 150 employees. By bringing in and gathering many experts from this industry, we can keep pace with the development of new technology and are able to provide creative products to meet different requests of our clients'. Right now, Enbon wins good reputation for its various ultra-thin and super-light rental outdoor and indoor LED screens, LED strip/mesh curtains, LED dance floor etc.
All our products have passed CE, FCC and RoHS certificates. 70% of our products are for export. We are an LED company you can count on for good quality and competitive pricing. Besides, you can also expect excellent pre-sale, selling and after-sale services here, which contains professional consultation, free training, free drawings, installation and 2 years warranty. We will inspect our products installed in domestic market periodically.
Enbon is equiped with advanced machines such as Automated Pick & Place machine, High Speed SMT, Wave Peak Soldering machine, Reflow Soldering Machine, High & low Temperature Aging room, Vibration tester, Waterproof tester, Anti-static & dust-free workshop etc. Modern automatic equipment together with our innovative engineers, dedicated workers and experienced sales and services team, we're the right supplier you can trust for good solutions for all your LED display projects.
Contact us for an offer today! Our team will respond in 1 working day. We look forward to be your good partner and grow together!
