P3 indoor full color digital display wall from ENBON,
111111 pixels/sqm. High resolution indoor LED screen. It's designed for high end market as the price is very high. Can show extremely clear video, images and texts. Best solution for conference to show powerpoint etc. Black body LED lamp for high contrast rate.
Features:
1. We use
SMD2121 black body LED, can get very high contrast rate: 9000: 1
2. High resolution, Up to Pitch 3mm. 111111 pixels in 1 square meter. With high density, it is the most popular for
high end market considering the price is competitive based on so good performance.
3. Large viewing angle,
Up to 140° (Horizontal & Vertical) by using our specially design mask.
4. Linsn control system, guarantee very high refresh rate,
no scaning line when taken photos or videos.
5. P3 LED video displaly, we use
Die-casting aluminum cabinet, high precise and ultra-light.
6. Our LED display takes with fast heating spread, to protect screen effectively and increase the use life largely.
7. ENBON P3 LED screen is designed as slim body & light weight, Easy maintenance.
8. This display can show all kinds of word, text, graph, pictures, flashes, video, 2-dimension, 3-dimension cartoon and any other formats synchronously with PC.
9. Different signal resources input are acceptable, such as TV, HCTV, S-video, NTSC/PAL, DVI, AVI, VGA, SDI, MOV, MPG, etc.
|
Technical Prameters |
|
PROJECT |
P3 indoor full color digital display wall |
|
Pixel pitch |
3mm |
|
Pixel density |
111111 Pixels/sqm |
|
Module size(W*H) |
240 (mm)W*240 (mm)H |
|
|
Module pixels(W*H) |
80 Pixels(W)*80 Pixels(H) |
|
|
Pixel configuration |
1Red 1Green 1Blue |
|
Drive mode |
constant current driving 1/16 scan |
|
LED lamp type |
SMD2121 (black body) |
|
Cabinet size(W*H*D) |
480(mm)W*480(mm)H |
|
|
Cabinet resolution |
160 Pixels(W)*160 Pixels(H) |
|
|
Color scale |
65,536 degree |
|
View angle(H/V) |
140/120 degree |
|
Brightness (White balance) |
≥1500cd/sqm. |
|
Power consumption(one cabinet) |
Max:1000W/sqm. Average:350W/sqm. |
|
Operating Voltage |
AC100V±10% or 220V ±10%; 50---60HZ |
|
Net weight |
39 Kg/M 2 for Iron cabinet |
|
Operating temperature |
-20°C----+50°C (Customized power supply:-45°C---+60°C) |
|
Operating humidity |
10%_95%RH |
|
Life time |
≥100,000hours |
|
MTBF |
5,000 hours |
|
Whole Display Flatness |
≤0.3mm Juncture |
|
Frame frequency |
>60 Hz/s |
|
Refresh rate |
≥1200Hz /s |
|
Control distance |
100m (without repeater), single mode fiber:20km, multi mode fiber: 500m |
|
Power |
110V/220V±15% 50--60Hz |
|
LED control system |
LINSN,Dbstar,Nova-star,ZDEC,Colorlight is selectable |
|
Operating system |
Windows 2000 / Windows Xp / Windows 7 |
|
Protections for outdoor display |
IP31 |
|
Maintenance way |
Rear Access |
|
Accepting signal with video processor |
PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI |
ENBON optoelectronics Limited is a High-tech enterprise specialized in R&D, manufacturing and sales of outdoor & indoor LED display. It was established in Jan 15, 2010 covering an area of 1 building with around 150 employees. By bringing in and gathering many experts from this industry, we can keep pace with the development of new technology and are able to provide creative products to meet different requests of our clients'. Right now, Enbon wins good reputation for its various ultra-thin and super-light rental outdoor and indoor LED screens, LED strip/mesh curtains, LED dance floor etc.
All our products have passed CE, FCC and RoHS certificates. 70% of our products are for export. We are an LED company you can count on for good quality and competitive pricing. Besides, you can also expect excellent pre-sale, selling and after-sale services here, which contains professional consultation, free training, free drawings, installation and 2 years warranty. We will inspect our products installed in domestic market periodically.
Enbon is equiped with advanced machines such as Automated Pick & Place machine, High Speed SMT, Wave Peak Soldering machine, Reflow Soldering Machine, High & low Temperature Aging room, Vibration tester, Waterproof tester, Anti-static & dust-free workshop etc. Modern automatic equipment together with our innovative engineers, dedicated workers and experienced sales and services team, we're the right supplier you can trust for good solutions for all your LED display projects.
Contact us for an offer today! Our team will respond in 1 working day. We look forward to be your good partner and grow together!
