| Item | Parameter |
| Model | P20 full color LED module |
| Module size | 320mm * 160mm |
| Pixel pitch | 20mm |
| Pixel density | 2500dots/m² |
| Pixel configuration | 1R1G1B |
| Module resolution | 16dots(W) * 8dots(H) |
| Driving method | Constant current driving |
| Scan method | Static scanning |
| Interface way | HU40 |
| Brightness | ≥7000cd/m² |
| Cabinet size | 960mm * 960mm |
| Power supply mode | 5V/40A 5V/60A |
| Optimal viewing distance | 20M - 50M |
| Optimal viewing angle | 160º(W) 120º(H) |
| Environment temperature | -20º ~ +50º |
| Relative humidity | 10% - 95% |
| Operating voltage | AC220V ± 10% |
| Average power | 300W/H |
| Max power consumption | ≤600W/m² |
| Control mode | Synchronization with PC |
| Driving device | IC constant current driving |
| Refresh rate | ≥600HZ |
| Gray/Color | RGB each 256 grade,can display 16.7M color |
| MTBF | ≥9000hours |
| Power switch | Automatic switch |
Product Features.
1. High brightness DIP LED is used for outdoor led display, keeps the display content visible even if facing
the strong sunshine directly.
2. Weatherproof design, completely outdoor use.
3. With Anti-UV ray mask, the color of the mask would never change even if under exposure of UV ray.
4. Easy for assembling and connection with the connector added.
5. High color uniformity and clear image can bring you a vivid audio visual effect.
6. Both front and rear access are available.
7. Use the same level of red, green and blue led chips, which makes the image display of whole led display
more excellent and uniform.
Using range.
Widely used in a variety of needs large hall, sports arena,banking, telecommunications, government agencies, terminal, pier, railway stations, the stock market and other trading market, medical systems, electric power, galleries and other publicity, advertising, information dissemination, the guide places.
Service.
1. We guarantee all our display,modules for two years.
2. We provide technology training for free, which contains the operation and maintenance
training of the LED screen in the factory.
3. After sales,if have any problem about our products,you can inform us by E-mail,
we will reply you at once when we get it and will offer you a good solution to solve the problem.
Installation.
1. we can assist the training and technical support for customer in factory if need.
2. We can send our engineer to guide the installation for you,but the relevant cost should be paid
by your company.
3. Our technicians will offer CAD drawing to show how to install the LED display.
Delivery.
1. 10-20 working days after receiving deposit.
2. Before delivery,we will test the display and keep it light up for 72 hours at least.
Trade term: FOB Shenzhen,China.
Paymet term: T/T 30% deposit before production,the balance before delivery.
Packaging: Wooden case or flight case.
Shipping freight are quoted according to your requests.
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
