Home LED Light Products P20 Energy Saving Outdoor LED Display for Advertising

P20 Energy Saving Outdoor LED Display for Advertising

P20 Energy Saving Outdoor LED Display for Advertising
Price: US $ 100-1200/Square Meter
Trade Terms: FOB,CFR,FCA
Min Order: 1/Square Meter
Pay Type: T/T
P20 energy saving outdoor LED display for advertising

specifications:

Part Number

HERO-OD

Resolution

16(H)*8(V)

Pixel Pitch

20mm

LED Configuration

1R1G1B DIP346

Pixel Density
2500pixels/ m2

Module Size
320*320mm

Driving IC

MBI 5024

Driving Method

Static Scan, Constant Current

Cabinet Weight
65kg/sq.m.

Mechanical Ratings

Hanging Weight Support

2T

Surface Flatness

±0.25mm

Optical Ratings

Brightness
≥6500cd/ m2

View Angle

110°/70°

Gray Scale

16bits

Display COLOR
281trillion

Brightness Adjustment

0~100%

Power Supply

Operation Power

AC220V/50HZ or AC110V/60Hz

Max. Power Consumption

230W/ m2

Average Power Consumption

115W/ m2

Control System

Control Mode

Synchronous display with control PC by DVI

Frame Update Frequency

60~85Hz

Screen Refresh Frequency

300~1000Hz

Gamma Correction

-5.0~+5.0

Support Input

Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI

Control Distance

Ethernet cable<120m or Fiber Optic<10Km

Support VGA Mode

1024×768, 1280×1024, 1600×1200, 1920×1280

Brightness Correction

Pixel, Module, Cabinet

Environmental

Operating Temperature

-20°~+60°

Operating Humidity

10~95% RH

Operating Life

100,000hours

MTBF

10000hours

Protection Level

~

Out of Control Rate

<0.02%


Description:
1,constant current,noise reduction technology,LED display driving chip adopt advanced LED display chip system,which is the first-class in the LED filed,from features of such driving chip,constant current noise reduction technology is created to ensure that the effect of other noise source to LED display is the lowest.
2,brightness adjustment technology,to adapt to weather,LED display designed 256 brightness adjustment device to make sure LED display achieve best display effect,it makes LED display has best display effect in any environment.
3,strong convection type heat-extraction system,LED display body give out lots of heat when LED display is working,to ensure the whole LED display system work stably,a strong convection type heat-extraction system is  created after researching it's heat-extraction,because of heat transmission of aluminum,heat-extraction system is more stable,ultra-low energy consumption and advanced electronic circuit make it save 60% energy,comparing with traditional LED display.
4,exclusive custom adjust measures to local conditions to meet difference creative display requirements.


Applications:
Widely used in  stadium,square,billboard,business street,shopping malls,commercial centers,railway station,subway station,hotel,supermarket,store,hospital,restaurant,bank and other advertising.


Packing and transportation:
Professional packaging:wooden box or flight case.
The way of Packing can prevent the collision of LED screen effectively in the process of transportation, such as falling damage,etc.
Faultlessly solve your worries in the transportation.



About Hero;
7-year's experience in LED screen, our factory has the ability of processing, researching and developing led display to ensure the prolificacy.A strict quality control process to make sure the led display screens is with high quality.

After-sale service:
1) Warranty:
Free to solve the quality problems to ensure that equipment normal operation in the warranty period . At any time, we bear all the responsibility, when the problem is from the product itself.
2) Free maintenance:
Free warranty in the warranty period.
Only charge the cost of raw materials, provide spare parts and maintenance services for the lowest price after the warranty period.
3)quick response:
Response within 2 hours, non-artificial, general fault solution within 24 hours, and acceptable failure resolved within 48 hours.
4) Free support:
Through telephone or network to provide service support in real time, or with the help of a network for remote debugging support (software), to solve the problem.


Officer website: Http://www.led-hero.com
Prod Model: P20
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Lifespan: 100,000 Hours
Warranty: 2~3 Years
Factory Price: Available
Display Type: LED Video Display
Tube Chip Color: Full Color
IP Rating: IP65
Pixel Configuration: 1R, 1G, 1B
Certification: CCC
Pixel Pitch: 20mm
Display Function: Video Display
Application: Advertising/Image/Text
Scanning Mode: Static Constant Current
Pixel Density: 2500DOT/M2
Average Power Consumption: 115W/M2
Shenzhen LED-HERO Electronic Telechnology Co., Ltd was found in early 2007. Hero committed to the next generation of LED optoelectronic products development, production, sales and service. It is leading the trend of LED industry and providing a full range of solutions to its customers. It has become a modern, large scale, professional LED Photoelectric comprehensive product integration supplier. The products sell well in over 50 countries and regions in Europe, America and Middle East, besides more than 20 provinces across China.

"Hero' S products and solutions include various of indoor and outdoor LED display screen and lighting products with its advanced technology, superior technology design, personalized design elements, large-scale production capacity and diversified cooperation strategy to provide full LED integrated solutions.

"Beat by wisdom, win in morals"is still our insistent faith, Quality is the life of a company. From material purchasing to product researching, development, production, testing, packaging and shipment, Hero abides ISO9001: 2000 international quality control process to make strict control and scientific management, and to achieve perfection. The products have passed the RoHS, CCC, CE and other international quality certification which ensure that each product are stable, reliable, environmental protective.

Excellent talent is the soul. Hero relies on the humanized management, promoting hero culture, exerting employees to have masters spirit. It has established a systematized, specialized production procedure. And it has built a strategic alliance with LED raw materials suppliers and vendors which has realized the resource sharing, division, cooperation, mutual complementarities and high-efficient operation for providing an effective guarantee to Hero' S scale production and diamond quality.

To select Hero, you will win the promise of a hero!
