P2.5mm Advertising Display Indoor LED Display

Rental LED Display P2.5mm LED Screen   ,light ,color can be customized ,full magnesium design ,cooling well ,no fans,no noise ,Anti-interference .

P2.5mm advertising display indoor LED Display  techincal parameters
Unit Module	Item	parameter
	Model	ALS - P2.5 - 24S
	Module size	240mm*120mm*10mm
	Pixel Pitch	2.5mm
	Pixel Density	160000dots/m2
	Pixel Configuration	1R1G1B
	Package mode	SMD2121
	Module Resolution	96dots(W)*48dots(H)
	Max power consumption	20w
	Module Thickness	10mm(without magnet)  13mm (with magnet )
	Module Weight	0.21kg
	Driving Method	Constant Current Driving
	Scan Method	1/24scan
	Interface Way	HUB75E
	Brightness	≥1000cd/m2
Unit Module	dimension	480mmx480mm
	Quantity of Module	8
	Thermal discharge	fan 2pcs
	Power supply Mode	5V/60A* 1pcs
	Pixel per cabinet	192mm*192mm
	Thickness	85mm
	Optimal Viewing Distance	2M-10M
	Optimal Viewing angle	160°(W)120°(H)
	Enviroment Temperature	Storage :-35ºC-+85ºC work :-20ºC-+50ºC
Power	Relative Humidity	20%-90%
	Operating Voltage	AC220V±10%
	Average power consumption	≤200W/m2
	Max power Consumption	≤300W/m2
	Current	≤20mA (Single LED )
Control system	CPU	Pentium4 or above P4 or above
	Operate system	WIN98/2000/NT/XP
	Control Mode	Synchronization with PC
Main technical parameter	Driving Device	IC Constant current driving
	Refresh Rate	≥400HZ
	Gray/Color	RGB each 256 grade, can display 16.7M clolor
	MTBF	≥9000hours
	Power Switch	Automatic Switch
	Display Mode	800*600/1024*768
P2.5mm advertising display indoor LED Display


Features & Technology Specification:

1. Widely application field and short ROI time. Commercial advertising LED display screen, Stadium perimeter LED display screen, mobile trailer LED display, LED screen for mobile media, shopping mall LED display, screen for logo showing, LED display for bank or stock exchange rate showing, LED moving sign for train and bus station, LED display screen for air port, elecommunication LED display screen for information showing and instruction and ect.

2. Clear Vivid image quality displaying. Even in direct and full-on sunlight day to ensure you attract more audience to get short ROI of your LED display screen's investment.

3. Long term brightness. More than 6000 nits brightness for outdoor full color LED display, more than 800 nits brightness for indoor full color LED display capacity throught products lifetime of LED display screen.

4. Easy installation and programming. Easy and simple installation interface, use friendly software to ensure the user programme the LED display screen system.

5. Convenient servicing. Front and rear cabinet access makes maintenance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.

6. The list of availabe models of our LED display/screen/panels/signs. P4mm, P5mm, P6mm, P7.62mm, P10mm, P12mm, P16mm, P20mm, P25mm, and ect.

Trade terms :	1. Payment:T/T,30% deposits before production,70% balance to be paid before delivery .
	2. Shipping freight are quoted under your requests .
	3. Shipping port: Shenzhen,mainland China .
	4. MOQ:1SQM .
	5.Package : Wooden packing and flight packing .
About Technology :	1. We provide the technology training for free, which contains the operation training and maintenance training at our factory
	2. We will send our engineers to your country by negotiation.
	3. We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
	4. We will send our engineers to your place if we are expected after our negotiation.

OUR COMPANY offers user-friendly products that optimize productivity and business efficiency and maintain the highest standards of design and quality. Customer satisfaction is our prime objective and our high quality LED video display screen used in more than 140 countries and win a high reputation.


OUR COMPANY provides onsite product installation, debugging and maintenance service for our LED display. Such as:
1. After-sales service:

1) Service principles: Response in time, solve problems as soon as possible and ensure the use.
2) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
3) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
4) Under normal use and storage, Our Company will be responsible for the equipments.


2. Pre-sales service:

1) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with client to find solutions.
2) Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection
