Type: PH8
Pixel pitch(mm): 8
Pixel density(DOT/m² ): 15625
Pixel specification: 1R1G1B
View degree: 110
Module size: 256mm*128mm
Module resolution(DOT * DOT): 32*16
Module number / cabinet: Depend on cabinet size
Grey level(level): 4096
Refresh rate(Hz)>380
Brightness(CD/)≥ 8500
Weight(kg/m² ): 35
Display color(color): 16777216
Visual distance(m): >8Power(w/)Max: 800
Average value: 266/m²
Drive mode1/4 scanning, Constant-current drive
Blind spot rate: ≤ 0.0003
Lifetime: 50000 hours
Working voltage (V): 220∨ /110V± 15%
Working temperature: (º C)-20º C~60º C
Working humidity: (RH)10%~90%RH
Control mode Synchronous control
Control systemPCTV card +DVI display card+ main control card +fiber transfer
SoftwareLED by studio or the user
Computer WINXP/WIN2000/WIN98 etc.
Display cardDVI
Control distance Twisted-pair 100m, Fiber ≥ 500m
|
No. |
Name |
Chip brand |
Chip type |
Wavelength |
Brightness |
Number |
|
1 |
Red |
Epistar |
9mail |
620-624nm
|
500-600mcd
|
1pc |
|
2 |
Green |
Epistar |
12*13 mail |
522±4nm
|
1100-1320mcd
|
1pc |
|
3 |
Blue |
Epistar |
12*13 mail |
470±3nm
|
260-300mcd
|
1pc |
Shenzhen Yilong LED display Co., Ltd.Is specialized manufacturer in LED display and LED lightings, which was founded in year 2006.Yilong intergrates designing, manufacturing, sales, engineering services also after services.The quality system management ISO9001 and with many facilities as high-speed fully automated SMT machine, fully automated glue-pouring machine, reflow ovens, wave-soldering, also engineers with rich experience and skilled workers.
With an excellent quality and services, Yilong has owned rich customers'reputations both from China also from other countries in the world as Taiwan, Hong Kong, Singapore, USA, South-Africa, etc…Our main products include LED display screen single color, bi-color and full color and various modules.
Importers, buyers, distributors, wholesalers, retailers, agencies, representations, trade, suppliers, vendors are all sincerely welcomed to join Yilong will be the best partner to your further successful business.
