Feature and Advantage
1. Waterproof and dustproof: IP68front, IP65back
2. Best viewing distance: 10-300m
3. Horizontal viewing angle: 120degree
4. Working temperatue: -20degree-+80degree
5. MTBF: More than 10, 000hours
6. Life span: More than 100, 000hours
7. Contrast ratio: 1000: 1
8. Average power consumption: 200W
Application and Market
1. Application
Wide applied in stadiums, advertisement, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
2. Market:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, MID East, Eastern Asia, Western Europe
Our service
1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM&ODM, any your customized lightings we can help you to design and put into product
3. Distributoership are offered for your unique design and some our current models
4. Protection of your sales area, ideas of design and all your private information
5. Top quality+Reasonable price+Responsible After Service=Successful & Win
Trade Terms
1. Package: Anti-shaking wooden package, Air flight case or Carton package
2. Payment: T/T, 40% deposits before production, 60% balance to be paid before delivery
3. Shipping freight are quoted under your requests
4. Shipping port: Xiamen,Fujian, China
5. Warranty time: 1years
6. Delivery time: 3-12working days
Description | Technical parameter |
| Specification | Module size | 320*160mm |
| Pixel pitch | 10mm |
| Pixel density | 10,000dots/m2 |
| Pixel configuration | 1R |
| Pixel resolution | W:32dots*H:16dots |
| Total weight | 45kg/sqm |
| Best viewing angle | 10-100m |
| Temperature | Storage: -35degree~+85degree |
| Working: -20degree~+80degree |
| Operating ambient humidity | 10%--95% |
| MTBF | ≥10,000hours |
| Life span | ≥100,000hours |
| Flatness | Tolerance of interpixel ≤0.3mm |
| Tolerance of modules clearance≤0.6mm |
| Power switch | Automatic switch |
| Horizontal viewing angle | 120degree |
| Vertical viewing angle | 110degree |
| Warranty time | 1years |
| Control method | Synchronization or asynchronization |
Shenzhen LED World Co., Ltd has focused on export business since 2009, who specialized in supplying the solutions of LED display screens, LED signs for worldwide market. The products series include small pixel pitch LED display, rental LED display screen, advertising LED display, stadium LED sign, LED ball screen, LED floor screen, creative LED display screens and so on. The above products are widely used in advertising media, public facilities, sports, entertainment, military, traffic and other industries, exported to USA, Mexico, Greece, Spain, Italy, UK, Thailand, Uganda, Nigeria, Russia, India, Turkey, Thailand, Vietnam, Brazil, Australia etc more than 20 countries and regions, and gained good reputation form the clients.
LED WORLD depends on the excellent outstanding R&D technicians, skilled & experienced oversea sales team, who adhere to" customer first, quality first, reputation first" as operating principle, making our future is better and better day by day.
Warmly welcome you visit our company to innovate and win glory together.
