Features:
1. Modularity cabinet(making them ideal for stacking)
2. Soft rubber mask(facia)-durable during impact
3. Soft protection board on the top of cabinet
4. Quick fix stabilizer(simple action)-see picture across
5. Special plastic coated hinges- see picture across
6. Simple cable connections-see picture across
7. Corrosion resistant coatings(extreme weather conditions)
8. Special interlocking cables- do not pop off during impact
9. Cabinet t IP65-cabinet
10. Upgraded conformal coatings(extreme weatherproof)
11. Improved air circulation- cooling within the housing
12. Improved control system and fiber data connections
13. Fewer operating cables- simple connections
Application Case:
LED Sport Perimete Diagram:
|
Item |
|
|
|
Model NO. |
P10 |
P16 |
|
Pixel Pitch |
10mm |
16mm |
|
Pixel Configuration |
2R1G1B |
1R1G1B |
|
LED Type |
DIP 3IN1 |
DIP 3 IN 1 |
|
Density |
10000 dots/m2 |
3906 dots/m2 |
|
Brightness |
>8000NIT |
8500NIT |
|
Color Temperature |
6500-9500K |
6500-9500K |
|
Scan Method |
Static Scan |
Static Scan |
|
Cabinet Size |
1280x960x180mm |
2560x896x90mm |
|
Module Resolution |
32x16 |
16x8 |
|
Cabinet Resolution |
128x96 |
160x56 |
|
Cabinet Weight |
50Kg/cabinet |
85Kg/cabinet |
|
Max. Power Consumption |
700W/m2 |
850W/m2 |
|
Ave. Power Consumption |
300W/m2 |
320W/M2 |
|
Best View Angle |
H:120 Degrees, V:60 degrees |
H:120 Degrees, V:120 Degrees |
|
Refresh Rate |
8000Hz |
2000Hz |
|
Gray Scale |
12-16bit |
12-16 bit |
|
Best View Distance |
>16m |
>16m |
|
Protection Level |
IP65 |
IP65 |
|
Cabinet Material |
Iron |
Iron |
|
Operation Voltage |
110-220V AC 50-60Hz |
110-220V AC 50-60Hz |
|
Working Temperature |
-20-+60 degrees celsius |
-20-+60 degrees celsius |
|
Working Humidity |
10%-90% |
10%-90% |
|
Signal Input Source |
VGA, DVI, HDMI, SDI, HD-SDI |
VGA, DVI, HDMI, SDI, HD-SDI |
|
Control Distance |
Ethernet cable:100m, Multi-mode optical fiber:500m,singel-mode optical fiber:20Km |
Ethernet cable:100m, Multi-mode optical fiber:500m, singel mode optical fiber:20Km |
