P10 Full Color Outdoor LED Display

P10 Full Color Outdoor LED Display
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Square Meter
Pay Type: L/C,T/T,Western Union,Paypal
Product Name: Outdoor full color LED display
1)High brightness;
2)Good flatness;
3)High contrast;
4)High energy saving display can save 50% more than traditional display.

* Products Advantages:
1) Price Advantage: We have the best competitive price at the market, also have the same even better quality.
2) Performance Advantage: Best Equality, high consistency, Big viewing angle, can repair each LED lamps
3) Quality advantage: From material to finished product, from design to produce, we control all steps, that's the guarantee of the quality and reliability.
4) Service advantage: Better service at same situation, better cooperation at same service!
Pixel Pitch Pixel Configuration
10mm Lamp (1-Red, 1-Green,1-Blue)
Color Brand Origin wavelength Brightness
Red OPTO TW 625±5nm 600 + 20% mcd
Green SILAN CN 525±5nm 1800 + 20% mcd
Blue SILAN CN 465±5nm 450 + 20% mcd
Color matching R:G:B/3:6:1, In order to reach the best white balance effect.
     LED Module Parameter
Dimension Definition Shell Working Voltage
Mm Dots Hi-quality &anti-fire PC V
160 x160 16 x 16 DC5
 Cabinet Parameter
Dimension definition Material protection level weight
mm dots   Front/Rear kg
960*960 96*96 Steel IP65/IP56 56
 Whole LED display Parameter
Density 10,000dots/m²
Best viewing distanse 5m-55m
Display Capabilities Video, Text, Graphics, etc
Input Signal HDTV,NTSC, PAL, S-video, VGA
Display Colors 16.7M colors
Processing/Color Depth 14bit
Gray Levels 4096 levels Shades
Refresh Rate >600Hz  (adjustable)
Avpower Consumption 600Watt / m²
Lifetime of LEDs More than 100,000 Hours
Input Voltage AC220V / 380V + 10%
(three items and five lines
Exchange frame speed 60Hz
Vertical Viewing Angle 60°
Horizontal Viewing Angle 120°
Way of Drive 1/4 scan constant current
Control mode To be synchronized with computer monitor
Brightness >7500cd / m² ( adjustable )
Requirement of System environment - 20ºC~ 60ºC, 10% - 90%RH
Communication Distance For 5 types of line(IBDN), no more than 150 meters; for fiber, no more than 5000 meters.
Prod Model: DHX-P10
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Tube Chip Color: Full Color
IP Rating: IP65
Pixel Configuration: 1R, 1G, 1B
Pixel Pitch: 10mm
Display Function: Video Display
Scanning Mode: 1/4 Scan
Certification: RoHS
Pixel Density: 10000 dot / m²
