Specifications:
Pixel pitch: 10mm
Refresh rate: ≥1920Hz
Brightness: 5500 CD/
Cabinet Size: 960*960*148mm
Cabinet Weight: 48kg
Outdoor HD LED Display Leader
Outdoor HD LED Display leader, mature product, functions two years ahead of competitors, worldwide fantastic projects.Modules help clients upgrade to better resolution. Increase the chance to have the second sales and enhance the relationships with clients.
Protection Rate IP65 and Module Style Design
Protection rate IP65, installation without frame. Module Style Design, fast installation and easy maintenance with low cost.
No Distortion, Power and Control System Back-up Technology
Deep black surface, firm & flat, anti-UV mask, make sure the flatness and no distortion. Power and control system back-up technology solution available.
Application Places
Ideal for outdoor advertisement media, government& enterprise project, culture & tourism, sports, propaganda image, commercial real estate.
Module features:
1, standard design, specific series, combined structure,Dark black and Durable: It is special
formulated with module plastic materia with deep black; it is strong and durable and its contrast
is higher than conventional products, strong and durable.
2,All modules are in standard and uniform size:320*320mm
3,Replacing parts of the general modules will be easy and convenient. We offer the service of
replacing the old modules with the new ones directly.
Cabinet features:
1,Its size is 960mmx960mm and perform all the distance of indoor and outdoor display cabinet.
The seams are reduced more than 50% and smoothness increases by leaps and bounds.
2,Simplify the installation and maintenance: If familiar with one, you should master the whole.
This can reduce the difficulty of marketing, engineering, training, maintenance and can reduce
the workload.
3,Standard production in a faster and more flexible way is possible because we have reserved
standard general cabinets and the shipment can also be made rapidly.
Our service
1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM&ODM, any your customized lightings we can help you to design and put into product
3. Distributorship are offered for your unique design and some our current models
4. Protection of your sales area, ideas of design and all your private information
5. Top quality+Reasonable price+Responsible After Service=Successful & Win
6. Chipshow can offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and led large screen full color display.
Trade Terms
1. Package: Anti-shaking wooden package, Air flight case or Carton package
2. Payment: T/T, 40% deposits before production, 60% balance to be paid before delivery
3. Shipping freight are quoted under your requests
4. Shipping port: Shenzhen, Mainland China
5. Warranty time: 2years
6. Delivery time: 3-12 working days
Module Parameter |
Item | Specification Parameter |
| Pixel Pitch,Resolution rate,size | 10mm,32*32 Dots,320*320*28mm |
| Pixel color, Pixel LED | 1R1G1B, SMD3535 |
|
| Working voltage,Module Power | DC5V,75W |
|
| Driving IC,Driving way | JXI5020B,1/2 |
| HUB | HUB 73 |
| Cabinet Parameter | Material,Cabinet Weight(kg/Cabinet) | Iron,48kg/Cabinet |
| Resolution rate,size,Module quantity | 96*96Dots,960*960*148mm,3*3 |
| Density | 10000 Dots/ |
| White balance ,Color temperature | 5500 CD/,6500K |
| view angel,Non-Flatness,Module interval | H:120°;V:120°,<0.5mm,<0.5mm |
| Maximal power/,Average power/ | 850W/,300W/ |
| Frame frequency,Refresh frequency,Gray grade | 60Hz,≥1920Hz,13bit |
| Control system,System supports | Novastar / Linsn /,Windows XP,WIN 7, |
| Working temperature,Protection grade | -20ºC - +50ºC,Front/Back:IP65/IP54 |
Package Parameters: |
|
Gross Weight: | 113kg (Estimated data,2pcs /Case) |
| Outer Package Size : | 1030*388*1150mm (Estimated data,2pcs /Case) |
| Packing Material : | Carton+Pearl cotton +wooden pallet |
