Outdoor SMD LED Display

Outdoor SMD LED Display
Price: US $ 1-2000/Square Meter
Trade Terms: FOB,CFR,CIF
Min Order: 1/Square Meter
Pay Type: L/C,T/T,Paypal,Western Union

P6 Outdoor Waterproof SMD Rental Full Color LED Wall Display Screen

Specifications

CLC Display  Full Color Outdoor LED Display
1.CLC Display outdoor smd Full Color LED Display

LED Display, Indoor outdoor LED Display,  Full color LED display:

P6 LED Display uses state-of-art LEDs, which has the brightness for indoor and outdoor application. The LED display has the advantage of excellent flatness, super uniform color and brightness. The LED Display has long viewing distance. The LED display cabinet of the rental LED display use aluminum which make the weight very light and easy to assemble.


Outdoor full color LED display could be used in outdoor environment such as cultural or relax square, commercial walking street, residential sub-district, downtown, etc. Place, with the speciality of dampproof, windproof, sunproof, staticproof, antifreezing, waterproof, its purpose is to propagandize outdoor advertising or play the important news or events or TV program, enrich the resident's cultural life, advance the whole visualization of sub-district, etc.

2. Features of the product:

1) High brightness and be adjustable, meets the need of the changing requirement of customer in environment.
2) Having good lightening accordance and no mosaic.
3) Using virtual pixels, better viewing effect for both text & graphic and video.
4) Having larger viewing angle: Horizontal angle 100 degree / elevation angle 45 degree. Getting vivid effect within any position of the viewing range.
5) Any led in each pixel can be respectively repaired, which reduce the cost of the display maitenance.
6) Good heat emission capability
7) Environmental-friendly.

3. Description:

1). Model No.: P10m, P12mm, P14mm, P16mm, P18mm, P20mm, P25mm, P31.25mm, (DIP LED)
2). Display Color: 256*256*256
3). Led Chips: Nichia, Cotco, Cree, AXT, Taiwan
4). Raw Materials: Toshiba IC, MBI IC, Chuanglian Power Supply, Meanwel Power Supply, Meanwel fans, ADDA fan, Beijing glue, Korean glue.
5). Cabinet: Standard cabinet, simple cabinet, customized cabinet, cabinet for rental, Iron or Aluminum cabinet, cabinet for front maintenance, cabinet with lock, Special cabinet with Southco Lock, for hung and rental and so on.
6). Package: Flight box, wooden box package
7). Guarantee: 1 year with parts




Module
           Item         Parameter
Model NumberP6-8S
Module size192mm*192mm
Pixel pitch6mm
Pixels Density27777/m2
Pixel configuration1R1G1B
Package modeSMD3535
Pixel resolution32dots(W)*32 dots(H)
Max Power 20W
Module thickness17.05mm
Weight0.202kg
Drive typeConstant drive
Scan mode 1/8scan
Port typeHUB75-A
Brightness of white balance≥6500cd/m2

Prod Model: P6-8S-O
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Module Pitch: 6mm
Waterproof: IP65
Package Mode: SMD3535
Brightness: 6500-6800CD/Sqm
Viewing Angle: H:160 W:160
Warranty: Full 2 Years
Life Time: More Than 100,000 Hours
Tube Chip Color: Full Color
IP Rating: IP65
Pixel Configuration: 1R, 1G, 1B
Display Function: Video Display
Average Power Consumption: 300W / m²
Scanning Mode: 1/8 Scan
Display Type: LED Video Display
Application: Advertising
Certification: CCC
Pixel Pitch: 6mm
Pixel Density: 27777dots/Sqm
Shenzhen Huaxia L&C Display Technology Co., Ltd(CLC display company), a LED display company located in Baoan district, Shenzhen. Based on our 3 factories(total 15200 square meters), we designs and develops visualization solutions for a variety of products selected from professional markets: Advertisement, Media, Sports, Entertainment, digital cinema, CCTV security, simulation & virtual reality. In these markets, Huaxia offers user-friendly imaging products that optimize productivity and business efficiency.

Integrating visualization technology requires specialist know-how and expertise and that's exactly what we can offer you - before, during and after the sale. We offers a complete range of high-impact video display systems, image processing and content management technology for permanent installations, rental and staging markets. Based on our staff with a couples of experience, We provide the right visualization technology to match your needs.

As a OEM/ODM factory, we are supplying both LED display and LED module to the overseas and domestic buyers. We supports our customers to finish more than 1, 500 events every year, which are from more than 60 countries and regions.

Main product list:

Indoor display, outdoor display, outdoor/indoor display mesh

Pixel pitch:

From P1.5, P1.875, P3.0, ...P31.25

Application locations:

Outdoor, Indoor and semi-outdoor

Application markets:

Advertisement, Media, Sports, Entertainment, Digital cinema, CCTV security, Simulation & virtual reality
