Keywords: LED Display,Outdoor LED display screen , Outdoor led screen, Outdoor LED panel, Outdoor die-casting aluminum LED screen.
Features:
1, Adopting SMD3535 LEDs,Big viewing angle(>140°H;>140°W) ,with a nice flatness appearance of led screen;
2,Hight brightness>5500CD/SQM(adjustable), The people can the video/pictures the sunshine.
3, Die-casting aluminum molding. Tiny splicing gap, light weight & ultra-thin cabinet.
4,With waterproof glue appearance. Front side IP65,rear side IP54, which can be used in outoodr and indoor.
5,Joint,stacking up and hoisting easily & quickly with fast locks.
| Parameters | LW-RO6.7 LW-RO8 LW-RO10 LW-RO10 |
|
| Pixel Pitch (mm) | 6.66mm | 8mm | 10mm | 10mm |
|
| Pixel density(pix/m2) | 22545 | 15625 | 10000 | 10000 |
|
| LED Type | SMD3535 | SMD3535 | SMD3535 | SMD5454 |
|
| Viewing Angle | X,Y120° | X,Y120° | X,Y120° | X,Y120° |
|
| Brightness(nits) | ≥5000 | ≥5000 | ≥5000 | ≥5000 |
|
| Drive Method | 1/6 | 1/5 | 1/2 | 1/2 |
|
| Color Depth | 65536 |
|
| Refresh Rate(Hz) | 1920 | 1920 | 1920 | 1920 |
|
| Module Size (mm) | 320×160×16 |
|
| Cabinet Size(mm) | 640×640×80 |
|
| Cabinet Material | Die casting aluminum |
|
| Cabinet weight(kg) | 12 | 15 | 15 | 15 |
|
| Voltage | 110-240V |
|
| Average.power(W/m2) | 230 | 230 | 230 | 230 |
|
| Max.power (W/m2) | 700 | 700 | 700 | 700 |
|
| IP Grade | IP65/IP54 |
|
| Operating temperature/humidity | temperature:-20ºC~ 50ºC humidity:10~90%RH |
|
| Storage temperature/ humidity | temperature:-40ºC~ 60ºC humidity:10~90%RH |
|
| Lifetime(h) | ≥50000 |
|
| Compliant Standard | CCC(CE)Rosh |
|
Shenzhen LED World Co., Ltd has focused on export business since 2009, who specialized in supplying the solutions of LED display screens, LED signs for worldwide market. The products series include small pixel pitch LED display, rental LED display screen, advertising LED display, stadium LED sign, LED ball screen, LED floor screen, creative LED display screens and so on. The above products are widely used in advertising media, public facilities, sports, entertainment, military, traffic and other industries, exported to USA, Mexico, Greece, Spain, Italy, UK, Thailand, Uganda, Nigeria, Russia, India, Turkey, Thailand, Vietnam, Brazil, Australia etc more than 20 countries and regions, and gained good reputation form the clients.
LED WORLD depends on the excellent outstanding R&D technicians, skilled & experienced oversea sales team, who adhere to" customer first, quality first, reputation first" as operating principle, making our future is better and better day by day.
Warmly welcome you visit our company to innovate and win glory together.
