P10 Indoor Full Color LED Display Screen for Advertising and Rental Event
P10mm High Brightness Rental Outdoor LED Display Screen Features:
--Light Cabinet size 512mm× 512mm, just 14kg in weight comparing to 25 KGs of conventional same size cabinet. Available to lift the cabinet by One-handed, saving much assembling time.
--Thin Adopted Die-casting aluminum cabinet with features of high strength, toughness, Precision and hard deformation. Just 89mm in thickness as a whole comparing to 160mm of conventional cabinet.
--Fast Use the facile connection lock in the cabinet, Assembling: Push the lock and then turn the revolving handle; Dismantling: Turn the handle and pull the lock. 10s/PCS.
--Easy Used modular design, any cabinet of the screen is free of assembling and dismantling.
--Compatible New structure design satisfy the hoisting assembling and stacking assembling. Cabinet standardization, compatible Outdoor & Indoor variety pixel pitches.
--Low Excellent heat dissipation design, no fans and air conditioning are required. Prime structure design, no tools are required.
|
Item |
CL-P10 |
CL-P16 |
CL-P16-2 |
|
Pixel Pitch |
10mm |
16mm |
16mm |
|
Module Size |
160mmx160mm |
256mmx128mm |
256mmx256mm |
|
LED Package |
Oval 346 DIP |
Oval 546 DIP |
Oval 346 DIP |
|
Resolution of Module |
16 x 16 pixels |
16 x 8 pixels |
16 x 16 pixels |
|
Pixel Density |
10, 000 pixel/ m2 |
3, 906 pixel / m2 |
3, 906 pixel / m2 |
|
Brightness |
6500 Nits |
8000 Nits |
7000 Nits |
|
Drive Scan |
1/4 scan |
Static |
Static |
|
Viewing Angle(H/V) |
110° / 60° |
110° / 60° |
110° / 60° |
|
Module Maximum Power |
1, 200W/m² |
1, 000W/m² |
1, 000W/m² |
|
Working Enviroment |
outdoor |
outdoor |
outdoor |
|
Standard Cabinet Size |
960mmx960mmx185mm |
1024mmx1024mmx185mm |
1024mmx1024mmx185mm |
|
Other Features |
LEDs & Ics in Separated PCB |
LEDs & Ics in Separated PCB |
LEDs & Ics in Separated PCB |
Channel Cailiang (Zhangzhou) Optoelectronic Co., Ltd. is one of the biggest LED manufacture in China. Our factory have 30 PCS production line for Outdoor DIP Modules, 5 PCS line for Indoor SMD products and more than 1, 500 skilled workers. Our R&D team are comprised of a crew of 10% of total staff and most of engineers have more than 5 years experience in LED industry, which great support our new products developing or customized products according to customers' requests.
Our Main Business is Produce various LED Display Module and LED Display Panel for Customers' assemble. It' s avaliable supply all the components for assemble LED Display or LED Message Signs. Besides, we focus on offering whole proposal for LED Display Projects and Solutions. Not only for regualr type, we have continuously developed several Profiled Screens and achieved some proud success in developing Traffic Wireless Solution Display Screens.
In order to design and develop higher quality products, our R&D team always tries best to meet the US&Euro-standards for Electronic products, as well as to fulfill the special requirements from customers. Our products have been approved the German TUV- EMC Certification and Euro EN12966 Certification, and we have also achieved ISO9001: 2000, CCC, CE, FCC, RoHS Certifications.
with perfect designed products, integrated solution including both hardware and software, and superior product and service guarantee, Cailiang has been highly praised by domestic and overseas customers. We have been shipping qualified products and services to more than 50 countries and regions all over the world, such as in the USA, Japan, Russia, Sweden, Turkey, Poland, France, Israel, Argentina, Spain, Italy, etc.
We value the power of cooperative team work, we take "Quality & Honesty" as our belief, and "Being the Largest Global Supplier of LED display Solution" as our goal.
"Channel Cailiang" Sincererly Invite your participation!
