| Price: | US $ 120.00/Piece |
|---|---|
| Trade Terms: | FOB,CIF,FCA |
| Min Order: | 30/Piece |
| Pay Type: | T/T,Paypal,Western Union |
|
Light source |
black molded aluminium housing with 14 pcs FOUR in one RGBW 8W high MCD LEDs |
|
operational mode |
DMX 512 protocol, Auto, master/slave |
|
Electronic power supply |
AC 90-240V 50/60HZ |
|
ITEM DIMENSION: |
260*300*180MM |
|
ITEM WEIGHT: |
5KGS |
|
features |
1.color strobe effect and long life operation 2. IP65 water proof 3. Stand Alone,Linkable via 3-pin XLR cable,4-digital LED display |
|
various colors |
red,green,blue, yellow,white,pink,purple,cyan |
|
Remark |
DU hanging brackets for easy floor standing |
|
video website |
http://v.youku.com/v_show /id_XMzc0MDcyOTA4. |
|
Channels |
9ch |
|
channel |
value |
function |
|
1 |
1-255 |
Red from small to big brightness ( dimming ) |
|
2 |
1-255 |
green from small to big brightness ( dimming ) |
|
3 |
1-255 |
blue from small to big brightness ( dimming ) |
|
4 |
1-255 |
blue from small to big brightness ( dimming ) |
|
5 |
1-255 |
Master dimmer from small to full brightness |
|
6 |
1-255 |
Strobe from slow to fast |
|
7 |
0-30 31-255 |
Dimmer, color, macro Dimmer on at ch 1/ch 2/ch 3/ch 4 Color macro, the brightness can be adjusted by the master dimmer at ch 4 |
|
8 |
0-85 86-169 170-255 |
Dimmer, increasing brightness, then decreasing brightness, color following one by one Dimmer on at ch 1/ ch2/ ch3/ ch4 Increasing brightness, then decreasing brightness , the running speed can be adjusted by ch 8 Color following one by one, the running speed can be adjusted by ch8 |
|
9 |
1-255 |
Running speed adjustements When ch 7 at 86-169 or at 170-255, the speed adjustment works |
| Prod Model: | DORIS RGBW 14 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Light Source: | 14*Four in One RGBW 8W High Mcd LEDs |
| Operational Mode: | DMX 512 Protocol, Auto, Master/Slave |
| DMX Channel: | 9CH |
| DMX 512 Connection: | Linkable Via 3-Pin XLR Cable |
| Dimension: | 260*300*180mm |
| Weight: | 5.0kg |
| Base Material: | Aluminum Alloy |
| IP Rating: | IP65 |
| Certification: | RoHS |
| Beam Angle: | 25?? |
| Lifespan: | 50000 hours |
| Diffuser: | Tempered Glass |
| Electric Current Type: | AC |
| Input Voltage: | 90-240V 60/50Hz |
| Emitting Color: | RGBW |
