Our product includes LED display, LED sign, LED screen, LED lighting fixture. Our professional technology is our best advantage in the industry. Strict Incoming Quality Check and Selection for Raw Material & Technology Advantages
Our advantage below:
1. LED: Antistatic>5000V
2. High temperature resistant>300° C
3.14mil LED chips
4.1.2mil gold wire
5. Copper brackets specially for LED display requiring cooling rapidly, excellent soldering performance.
6. Top quality of epoxy resin glue by Taiwan's top company. Anti-ultraviolet ray, expansion & shrinkage resisting
7. Adopting Japanese Nichia LED classification standard to ensure the uniformity of LED color & brightness.
8. Connectors: Above 2 mil brass connectors, phosphor copper, 100% salt spray PH experiment, difficult to be oxidated and corroded.
9. Extreme flexibility,
10. Pluggable times is above 200 times.
11. High endurance in normal climate with long life span>10 years.
12. Shell: Using PC of German Bell Co. High intensity, long life span, anti-ultraviolet, able to withstand outdoor rigorous ambient, high and low temperature resistance, fire with the UL standard grades.
Mask: Using special anti-ultraviolet non-shine process, good uniformity.
PCB: Using PCB with UL certification, thickness of copper>one ounce, greatly extending the useful life and enhancing corrosion resistance and reliability.
Power: All using Taiwan power with UL and CE certification, enhancing the reliability of the screen power supply.
Production Advantages
Equipment
1. SunYEX has several auto production lines equipment with Taiwan auto-encapsulate machine, Taiwan Chang-Yu handler, and the production of LED meets the demand of high quality standard LED display.
2. Using full set of injection machine to meet the high quality requirements for shells, masks.
3. LED lead-free reflection wave soldering machine.
Features:
1. High uniformity for LED
2. High performance of anti-vibration
3. Easy assembly
4. Extreme low blind LED rate.
5. CE UL FCC certified
|
|
P8 DIP Outdoor Full Color LED Screen Parameter
|
No. |
Type |
Full Color |
|
1 |
Pixel Configuration |
1R+1G+1B |
|
2 |
Module Resolution |
32pixels(H) × 16pixels(W) |
|
3 |
Module Dimension |
256mmH) × 128mm(W) × 160 mm (L) |
|
4 |
Power Consumption(average) |
600w/ m2 |
|
5 |
Power Consumption(max) |
1000 w/ m2 |
|
6 |
Density |
15625pixels/m2 |
|
7 |
Brightness |
>75000 nits |
|
8 |
Color |
16.7 M |
|
9 |
Brightness Control |
Manual/Auto |
|
10 |
Gray Scale Rectification |
r rectification |
|
11 |
Picture Regulation |
Contrast/Chroma regulation/Module brightness regulation |
|
12 |
Drive Mode |
1/4 duty |
|
13 |
Refresh Rate |
1080HZ |
|
14 |
Control Mode |
Synchronization control |
|
15 |
Video Interface |
S-Video, VGA, DVI etc. |
|
16 |
Display Mode |
1024 × 768 |
|
17 |
Life Time |
100,000 hours |
|
18 |
Mean Time To Failure |
>10,000 hours |
|
19 |
Blind LED |
None |
|
20 |
Temperature |
-35 °C ~+55 °C |
|
21 |
Relative Humidity |
10%-95%RH |
|
22 |
Display Flatness |
The display : ± 1mmGap between modules : 1mm |
|
23 |
Display Information |
Text, Video and Picture etc. |
|
24 |
Voltage |
220V ± 10% , 380V ± 10% |
|
25 |
Communication Distance |
<20km |
|
26 |
Waterproof |
IP65 |
|
SunYEX is a high-tech enterprise specializing in professional R & D, production and selling of LED screens. Our main products include LED display, and other LED lighting fixture. During SunYEX's these years' high speed developing, SunYEX has been working on building a friendly and win-win relationship with partners. We have a wide range of international strategic partners, sharing the benefits brought by international cooperation and division of labor. The international strategy enhances our technology and management level, promotes international quality standard certification and improves its competitiveness in the industry. Additionally, our international strategic alliance speeds up our process of establishing global service system and sales network and our international market further supports our expansion of domestic system and the strategic framework of the whole market. Nowadays, SunYEX brand is more and more recognized and praised by the industry and a wide range of users, which is derived from our efficient work, quality awareness, service awareness and customer awareness formed over years.
With our company's technology level, we have established strong and steady partnership with the world's toppest organisations such as PHILIPS, Toshiba and Siemens in developing product and operating control systems which we are proud of our quality.
SunYEX owns the most advanced LED assembly machinery and a Category 100, 000 dust-free workshop and powerful anti-static system, managed by a highly professional team which is well-known in the LED display industry, adding R&D administration, manufacture and extensive testing area, we believe we are now in a position to offer the world the best reliable product and COMPETITIVE COST for customers in the worldwide markets.
Our main products of SunYEX includes: LED Full Color Display, LED Single/Bi-Color Display, LED Traffic Light, LED Pharmacy Cross Display, LED Digital Tube, LED Solar Light, LED linear strips, LED modules, LED wall washers, LED fluorescent light, LED lighting fixtures, LED neon flex, LED components, LED accessories and so on, all of which are widely used in urban lighting decoration, advertising light boxes backlight, indoor home decoration, stage lighting, project, lights and cars, etc.
SunYEX has a well-trained team including full experienced technicians and salesman; "product quality and customer satisfaction" is our main aim. More and more people continue choosing SunYEX for our excellent quality and unique well service, currently, 95% of our products have been sold in Europe and many other foreign markets.
Our target: To become a worldwide leading LED products provider within 5 years!
