Spec and Parameters: Pixel Pitch: 10mm
LED configuration: IRIGIB
Brightness: 5500nits
Pixel density: 10000/sqm
Viewing angle: 110° H and 50° V
Lifetime: 60000 hrs
Power consumption/tile: Average 450W/m2, max 750W/m2
Operation power voltage: 200-240 V / 50-60 Hz
Tile/size (W× H× D) in mm: 960× 960× 120
Tile/display surface in sqm: 0.92
Cabinet Material: Steel
Cabinet weight: 60kg
IP rating: IP65/54
Color: 281 trillion
Processing: 16bit
Refresh rate: >2000Hz
Max power cascade connection: 5 cabinets
Operating temperature: -30-50 degree
Storage temperature: -20-60 degree
Operation humidity: 10-99%
Storage humidity: 10-90%
SHENZHEN KINGDIGITALS ELECTRONICS Co., Ltd. is one of the professional LED Products manufacturer in China. Our Main products is Indoor full color LED display, Outdoor LED display, Single/double color LED signs, Rental LED display and LED lighting. The main products of our company have been exported to North America, Europe, Southeast Asia and other regions.
For the past few years, we commit to promote our brand. On the same time, OEM and ODM business are also accepted. We understand the delicate balance between R&D, manufacturing and marketing both domestically and abroad.
Under the philosophy of "Quality First, Credit Top and Customer Uppermost", we keep improving in management and have gained unanimous recognition from domestic and foreign customers on quality, delivery and service.
Join us, we make more better tomorrow.
