Outdoor Custom Advertising LED Display (P10)
| Price: |
Negotiable/Square Meter |
| Trade Terms: |
FOB |
| Min Order: |
1/Square Meter |
| Pay Type: |
T/T |
Outdoor Custom Advertising LED Display (P10):
For outdoor LED display, the brightness and ability to adapt to harsh environment is very important.
The outdoor full color LED display screen of LEDER is available multimedia LED display system. It uses blur control arithmetic control technology to the auto-achieve regulation and white balance of luminance.
The display can work normally under the disgusting environment by its temperature self-adopted system.
|
Display and control feature |
Structure feature |
|
Specification |
Parameter |
Specification |
Parameter |
|
Pixel Pitch |
10 mm |
Module size |
160 mm*160 mm |
|
Pixel composing |
1R1G1B |
Display resolution/module |
16 dots*16 dots |
|
Wavelength (R) |
620-630nm |
Standard cabinet size |
960 mm*800 mm |
|
Wavelength (G) |
520-535nm |
Cabinet Weight |
≤ 65 Kg/sqm |
|
Wavelength (B) |
465-475nm |
Protection classification |
IP65 |
|
Wave Angle (H) |
110° (H)/ 50° |
Install mode |
Wallmount, hung and stand structure |
|
LED package |
DIP 346 |
Cabinet Material |
Iron/Aluminum |
|
Density per sqm |
10, 000 pixel |
Working power |
|
Grey scale |
12-16bit |
Specification |
Parameter |
|
Whiteness brightness |
≥ 6500 |
Working voltage |
AC 220v/50Hz± 10% or AC110v/50Hz± 10% |
|
Frame frequency |
60 Hz |
Average/Max power |
650W/1600W per sqm |
|
Refreshing frequency |
900-10, 000Hz |
Short circuit protection |
Yes |
|
Driving method |
1/4 Constant Driving |
Led Lamp type |
Nichia/Cree/Silan/OPTO |
|
Control mode |
synchronous |
Working environment |
|
Display port |
DVI |
Environment |
Outdoor |
|
Malfunction dot |
3/100, 000 |
Working temperature |
--20~50degree |
|
MTBF |
10, 000 hours |
Working Humidity |
10~90% |
| Prod Model: |
P10 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Pixel Configuration: |
1R, 1G, 1B |
| Pixel Pitch: |
10mm |
| Pixel Density: |
10000 dot / m² |
| IP Rating: |
IP65 |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Scanning Mode: |
1/4 Scan |
| Certification: |
CE |
| Average Power Consumption: |
650W/Sqm |
