Product Description
Product features:
1) Light, color can be customized
2) Full magnesium design, cooling well, no fans, no noise, anti-interference
3) A ssembly of high prcision, the gap can be controlled less than 0.2mm,
cabinet installation just 20 seconds
4) the cabinet size can be user-friendly ddesigned according to the module size
5) Fast disassembly module just 10 seconds, convenient replacement and maintenance
6) Durable cabinet stucture
P2.5 indoor Surface Mounted Module Technical Parameters
Unit Module | Item | Parameter | | Module | P2.5 Indoor Full Color Module | | Module Size | 240mm*120mm | | Pixel Pitch | 2.5mm | | Pixel Density | 160000dots/m2 | | Pixel Configuration | 1R1G1B | | Package mode | SMD2121 | | Module Resolution | 96dots(W)*48dots(H) | | Max Power Consumption | 20W | | Module Thickness | 10cm | | Module Weight | 0.21kg | | Driving Method | Constant Current Driving | | Scan Method | 1/24Scan | | Interface Way | HUB75-E | | Brightness | ≥1000cd/m2 |
Cabinet Module | Cabinet Size | 480mm*480mm | | Cabinet Composing | 8pcs | | Power Supply Mode | 5V/60A*1pcs | | Thermal discharge | Fan 2pcs | | Cabinet Resolution | 192*192dots | | Optional Viewing Distance | 2m-10m | | Optional Viewing Angle | 160°(W) 120°(H) | | Environment Temperature | Work :-10°C~+50°C | | Relative Humidity | 20%-90% | | Thickness | 85mm | | Power | Operating Voltage | AC220V±10% | | Average Power | ≤200W/m2 | | Max Power Consumption | ≤300W/m2 | | Current | ≤20mA |
Control System | Computer | Pentium4 or above P4 or above | | Operate System | WIN98/2000/NT/XP | | Control Mode | Synchronization with PC |
Main technical parameter | Driving Rate | IC Constant Current Driving | | Refresh Rate | ≥400HZ | | Gray/Color | RGB each 256 grade,can display 16.7M color | | MTBF | ≥9000hours | | Power Switch | Automatic Switch | | Display Mode | 800*600/1024*768 |
|
|
|
Application:
1) Large hall, sports arena, banking, telecommunications,
2) Government agencies, terminal, pier, railway stations,
3)Stock market and othertrading marketm medical systems,
4) Electric power,galleries, and other publicity, adverting,
information dissemination, the guide places, and so on.
