Famous brands raw material selection:
1. LED: well-known international brand, with wide viewing angle, high brightness, little attenuation, good heat dissipation, and vivid colors.
2. Driving IC: famous brands such as Netherland Philips, Japanese Toshiba, avoidable the defective phenomena, such as dark bright, virtual light and so on.
3. Power supply: industrial-strength brand. The power t maximum power reserve of 20% the space, the range of voltage fluctuation is less 5%, high stability.
4. Connector: aerial grade brands ensure the stable transmission of power and signal.
5. PCB Board: FR-4 A2 CCL, adopt 4-layer design.
Excellent display:
1. Highcontrast mask design: new antiglare mask design, fine sand processing and black coating on the surface, no glare, and improve the contrast.
2. Automatic SMT: adopting highend automatic SMT machine, advanced wave soldering and reflow soldering processing, to effectively avoid the wrong plug, plug leakage, leakage welding, virtual welding problems.
3. Module suite: improve the planeness of the whole screen, and reduce the seam between the neighboring modules.
4. Multi gray display: adopting 16bit gray processing technology to restore the natural image. And using S-PWM driving technology to add gray grade, meet the 16bits high gray display requirements with low brightness.
5. Point by point correction: the correction technology of brightness and chromaticity to ensure the uniformity of led screen's brightness and color.
Variety and easiness:
1. Various installation: cabinet assembly or magnetic suction installation
2. Easy maintenance: optional front maintenance, back maintenance and single point maintenance according to the installation site.
3. High contrast mask design
Products list:
1. P3\P4\P5\P6\P7.62\P10 Inndoor Full Color Led Display;
2.P6/P7/P8 /P10/P12//P16/P20/Outdoor Full Color Led Screen
Why choosed us :
1.Price Advantage: No.1 cost effective
2.Quality advantage: serious QC control system , best material
3.Service advantage: after service dept& Tech Dept. Perfect after sales system
MainTechnical Parameters of Full color Series
The specifications of modules |
|
Items | Parameter |
Product Model | P10 Outdoor Full Color LED Module |
Module size | 160mm*160mm |
Pixel pitch | 6mm |
Pixel density | 10000dots/m2 |
Pixel configuration | 1R1G1B |
Module resolution | 16dots(W)*16dots |
Module maximum power consumption | 25W |
Module Thickness | 2.5CM |
Module Weight | 0.5kg |
Driving method | Constant Current Driving |
Scanning method | 1/4scan |
Interface | HUB75 |
Brightness | ≥8000cd/m2 |
The specifications of cabinets |
|
Cabinet size | 960mm*960mm |
Module quantity | 25pcs |
Power supply | 5V/40A 5V/60A |
Cabinet resolution | 96*96dots |
Optimal viewing distance | 10M~50M |
Optimal viewing angle | 160°(W) 120°(H) |
RHWorking temperature | (Work :-20°C~+60°C) |
System operating humility | 10%-95% |
The specifications of power supplier |
|
Operating Voltage | AC220V±10% |
Average power consumption | 350W/H |
Maximum power consumption | ≤600W/m2 |
Electric current | ≤20mA(single LED) |
The specifications of control card |
Control Panels | Pentium4 or above |
Operating system | WIN98/2000/NT/XP |
Control model | Synchronization with PC |
The specifications of the main technical parameters |
|
Driving device | Constant Current Driving |
Refresh rate | ≥600HZ |
Grey scale | RGB Each 256, can display 16.7M colors) |
MTBF | ≥9000hours |
Power switch | Automatic Switch |
Display Mode | 800*600/1024*768/1280*900 |
Our services:
1.Your inquiry about our products or the price will be replied within 24 hours!
2.We provide 2 years for warranty and lifelong maintaining ,you will appreciate our warm after-sale service.
3.We will delivery goods as you demand ,you can choose the cheaper and more convenient way!
4.We can provide mature customised solution for you.
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
