Home LED Light Products New Arrived High Quality UFO LED High Bay Light

New Arrived High Quality UFO LED High Bay Light

New Arrived High Quality UFO LED High Bay Light
Price: US $ 151.2-163.8/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Paypal,Money Gram

Luminous source
The KULON I Series LED High Bay Lights are utilizing LUMILEDS® LUXEON 3030 2D luminous source, providing excellent lumens output - up to 150LPW(LM/W) @125MA, long-lasting stability and splendid sight
 INVENTRONICS LED Driver:
High end programmable EBD Series LED Driver, integrate dimming function and 6KV / 10KV surge protection. Provide excellent performance and lifespan.
Optimal heat radiation:
Excellent thermal management system and heat radiation enable the LED consistently work cooler, providing significant boosts to lifetime and efficacy.

Details Features:
Unique enbossing lens and reflector design, better industrial lighting.
Utilize Germany WAGO connector for output connections, safe, convenient and fast.
Utilize M16 waterproof connectors to fix the input cable, avoid damage of hard power pulling.
Neat inner cavity structure, ensure the thermal convection of LED Driver.
Simple ring structure design, easy for suspended mounting.
Entirely made in aluminum, not only exquisite the appearance, but also no corrosion concerns.

Features & Advantages:
1.  LUMILEDS® LUXEON 3030 2D luminous source
2.  High Reliable  programmable EBD Series LED Driver,(1-10VDC, Resistance, PWM or time dimming function available)
3.  KULON 3rd GENERATION LED MODULE: Exquisite design with powerful thermal performance, as well as high reliable waterproof
4.  Over then 100,000 hours operation life with 5 Years Warranty.
5.  Available for 60°, 90° and 110° beam angle.
6.  IK10&IP66 (testing reports available)
7. 10KV surge protection or motion sensor available.
8.  Adjustable mounting bracket or suspension wire mounted hang installation method available
9.  UL, DLC, RoHS, CE, GS, CB certificated is pending.
10.  IES file or Dialux simulation for lighting solution is available.
Specification:

Model No.K-GKD150WI
Nominal Wattage150w
Nominal VoltageAC 100-240V /277V, 50/60Hz
Maximum CurrentAC 0.41A -120V, 0.21A -240V, 0.18A -277V
Driver Efficiency> 90%
Power Factor (PF)> 0.95
CCT3000k 4000k 5000k 5700k
Operating Temperature-40 ºC to +50 ºC
RatingsIP65
Lumens Output(+/- 5%)15000 lm
Lumen Maintenance> 100,000 hours -L70(9K), @25 ºC (77 ºF)
Heat RadiatorAnodized Aluminum
LensTempered Glass
Dimming0-5v, 0-10v ,PMW, Time
LED BrandPhilips Luxeon
Driver BrandINVENTRONICS  EBD Series
Packaging 1unit  / ctn
Application:

kulon I series high bay fixtures were designed specifically to replace conventional lighting in a wide variety of indoor industrial applications; Their low profile light weight design and versatile mounting options make it ideal for many applications such as warehouse, garage, aisle, cold storage, bridge, tunnel and general area lighting.

Prompt lead time, professional Dialux lighting simulation, perfect after-sales service are our priority,
hope to be your reliable led lighting solution partner.
1. What we do is making you satisfied. Our goal is providing you with right products and come up with correct solutions.
2. Shipping will be the most economical for you and freight cost is informed in advance for your consideration.
Decision for the shipping terms will be made according to your requirements.
3. Delivery time is guaranteed. 2-3 working days for sample order,5-7 working days for regular order(quantity< 100pcs),10-15 working days for mass order(101-500pcs), order >500pcs pls contact us to confirm.
4. Price is negotiable if you have large quantity demand.
5. Package is customized.Usually we use films,foam boxes,cartons and wooden pallet.

Warranty details:
Hangzhou Kulon Electronics Co., Ltd. ("Kulon") warrants this kulon branded hardware product against defects in materials and workmanship under normal use for a period of FIVE (5) YEAR from the date of purchase.
Kulon provides free repair or replacement within warranty period. KULON shall charge against defeats by abnormal storage, useage, connection or change the structure or any commponents of the product.
(Professional Warranty file with stamp and signature will be sent to you if necessary)

Founded in 2005, Hangzhou Kulon Electronics Co., Ltd is a hitech and private enterprise devoted to R&D, producing and selling of high power LED outdoor / indoor lights, solar LED lighting systerm and more energy saving products and so on.

Adhering to the management concept of "honest cooperation, pragmatic innovation", we regard clients' satisfaction as our top task,
product quality as the basis of development, and cost-saving as our competitive advantage.

How to choose a right light for project?
1. According to Average or minum lux demands on floor to choose the right watt product
2. Depends on project drawing to make a Dialux simulation to confirm the beam angle and light installation layout
3. Choose the right CCT(3000/4000/5000 or 5700K) for different application place.
4. Confirm the most suitable install method. (pendant mounting, direct mounting or suspended mounting available)

How to achieve intelligent dimming function ?

Our led driver use Mean Well HLG type or Inventronics smart could support all kinds of dimmer:
0-10VDC, Resistance, PWM, Time dimming or DALI
You just need to connect a dimmer to achieve this function.

How to achieve motion sense function?

We could build in a smart motion sensor to ahieve this function such as:
When used in combination with 1-10V dimmable LED drivers and ballasts, the sensors can achieve 3-step
dimming function, 100%---> low light--->off. And the sensors build in adjustable daylight sensors, very easy to
install and cost-effective
Prod Model: K-GKD150WI
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Application: Supermarket Workshop Parking Lot etc
LED Driver: Inverter LED Driver
LED Chip: Lumileds Luxeon 3030 2D Luminous Source
Color: Silver Gray
Material: Aluminum Alloy + Toughened Glass
Power Factor(PF>): 0.95
Ratings: IP65
Operating Temperature: -40 Oc to +50 Oc
Lumbermen Output(+/- 5%): 12500
Dimming: 0-5V, 0-10V ,Pmw, Time
Lamp Body Material: Aluminum Alloy
IP Rating: IP65
Certification: VDE
Color Temperature: 3000k 4000k 5000k 5700k
Usage: Supermarket, Shopping Mall, Factory
Beam Angle: 60/90/110
Established in 2007, Hangzhou Kulon Electronics Co., Ltd. is a professional high-tech corporation focuses on deputizing power supply products of high quality, OEM, technical support, after-sale services, and providing practical resolutions to any power supply problems in an all-round manner. Our products cover the following series: Switch Power Supply, DC/DC Converter, , EMI/EMC Power Line Filters, Signal Isolation Amplifier Modules. These products are widely applied in the fields of mechanical equipment, instrument meters, industrial automation, electronic technology, telecommunication, information technology, lighting projects, medical appliances, and automobile industry, etc.

Adhering to the management concept of "honest cooperation, pragmatic innovation", we regard clients' satisfaction as our top task, products' quality as the basis of development, cost-saving as our competitive advantage. Meanwhile, we exert all-out effort to keep pace with the technological innovation and update our products in time; We hold tightly to the market demands and try hard to satisfy the clients' requirements. Depending on the mutual trust with enterprises of industry-leading brands and the excellent cooperative relationship of complementary advantages, the scope of our business is being enlarged constantly and the rapid development of our corporation has received congruous recognition and support from our cooperative enterprises. Our clients come from the fields concerning mechanical manufacturing, industrial automation, telecommunication, medical appliances, instrument meters, electric monitoring, textile industry, mining equipment, hardware tools, various lighting equipment and projects, security precaution facilities, and automation for buildings, etc. In a word, our clients cover every walk of life.

We ponder over matters by following the market demands and aim at meeting the satisfaction of our clients. The success of our clients is the ultimate value of evaluating our work. The core of a company's development is to pay close attention to the market changes and to keep pace with time. Our corporation has provided and will provide products and technology support of excellent quality to our clients and grow up together with our clients. Our earnest thanks go to our clients for choosing our products all the time and for their long-term and consistent support and cooperation with us. We earnestly welcome our clients and new friends from all walks of life to our company, carrying out business negotiations, extending our mutual professional work, and striding towards our common prosperity and promising prospects.
