Private product & open mould by ourself - effcetive cost
RGB Synchronization with our patented remote control system (Patent No.: ZL 2012 2 0640518.8)
IP68 Instructure waterproof (100% water-proof test ) with high pressure water-proof device
ABS lamp body material - good at heat dissipation
Wide range power: 12-35W to fit different environment requirement
Applicable LED chip: SMD, High Power, COB
Replace 80W-100W Halogen Light
Main Parameters
Specification | Parameters |
Model No. | LF-P56M-12W-T3 (SMD5050) |
LED Qty | 72pcs SMD5050 |
Input Voltage | AC/DC 12-13V |
Frequency | 50/60 Hz |
Power | 13±1w (White) 12±1w (RGB) 9±1w (R) 13±1w (G) 13±1w (B) |
Color Temperature | w.w.3000-3500K p.w.6000-7000K c.w.8000-10000K |
Luminous Flux | P.W. 800Lm±10% W.W. 750Lm±10% C.W. 700Lm±10% 150Lm±10%Lm (R) 550±10%Lm (G) 100±10%Lm (B) RGB: 250±10%Lm |
Color Rendering Index(CRI) | P.W. Ra≥70 |
Wave Length | R/G/B: 620-630/515-525/ 460-470 nm |
Beam angle | 120° |
Dimension | 250*118.5mm |
Working temperature | 0~40ºC |
Storage Temperature | 0~50 ºC |
Constant driver | yes |
IP rating | IP68 |
