Light Weight LED Display

Light Weight LED Display
Price: Negotiable
Trade Terms: FOB
Min Order: 1/Square Meter
Pay Type: L/C,T/T
LED Mesh/Curtain Display Screen
Feature
LED curtain display or mesh display looks like window-blinds, by advanced aluminum alloy with features of transparency, lightweight and thinness, integration of power supply and control device.
This kind of LED display can be displayed synchronously with the computer. Pictures, texts, TV, videos, VCD and kinds of three-dimensional animation can be displayed at random on it.
It's fast to install or dismantle and flexible to use, reducing time and labor. So it's suitable to be used in the occasions where need to be moved and detached freely.

Specifications:
Light, nice look face and transparent
Pixel pitch: 16mm
Pixel density: 3, 906 pixels/m²
Refresh rate: ≥ 600Hz
Brightness: ≥ 6500CD/m²
Pixel composition: 1R1G1B
Drive mode: Static constant current
Module size: 512mm
Cabinet size: 512 x 512mm
Weight: ≤ 7kg
Beam angle: <110°
Gray grade: 14 bits
White balance color temperature: 6, 500 (adjustable)
Contrast: 1, 000: 1
Operating voltage: 5V DC
Power supply: 100 to 240V AC at 50Hz
Protection: IP65
Interface mode: Aviation connector
Installation: Hanging or fixing
Power consumption: 600W/m² (average) and 1, 200W/m² (maximum)
Display interfaces: VGA, DVI, HDMI and 1, 000Mbps Ethernet port
Temperature -30 to 80° C
Operating humidity: -20 to 60° C
Humidity: 10 to 99%
Lifespan: 100, 000 hours
Pressure testing: 3, 000V/minute
Ground resistance: ≤ 0.1Ω
Drain current: ≤ 3.5mA
Gap between modules: ≤ 1mm
EMI: Meet EMC standard
Shockproof capability: Meets GB6587.4-86 testing standard
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Place Of Origin: Guangdong, China (Mainland)
Brand Name: Hangrand
Model Number: Hg-Op16m
Pixels: 16mm
Service: Service
Warranty: 2 Years
LED Chip: CREE/Silan/Opto
Delivery: 10-15 Working Days
Payment: T/T, L/C
Ingress Protection: IP65
Usage: Indoor
Tube Chip Color: Full Color
Display Function: Video
Certification: CE & RoHS
Shenzhen Hangrand Technology Co., Ltd. is a Hi-Tech enterprise specializing in LED displays, LED & LED lighting products and LED decoration products. We are mainly engaged in the production of outdoor&indoor LED displays, LED bulbs, LED spotlights, ceiling lamps, LED tubes etc.
Our products have gained national patent (Patent NO: 0226570.8). We also have passed CCC, CE, RoHS, FCC and UL Certifications. Our products have been sold to Europe, American, Middle East, Africa and Australia.
Our company is located in the Hengguan Industrial Park in Pinghu, Shenzhen. Our factory covers more than 10000sqm and has 600 employees including 50 senior technicians. Our highly skilled staff members and excellent management persons have implemented a strict quality supervision and inspection system, which ensures that our products can achieve international standards. Our R&D Dept. Has strong capability of developing new items in accordance with customers' requirements. OEM and ODM orders are welcome. We strongly believe in the tenet of "innovation forever, which can lead to a bright future".
We are looking forward to building up good business relationships with all customers based on mutual benefits. You are welcome to visit us and contact us for more details.
