2-5/8" depth
Front snap frame 1-1/14"
Internal transformer
Hardwire or plug in option
Zee bar for hanging
24 Volts DC
LED edge lit provides bright even illumination
75% less power consumption than fluorescent
Standard finishes of anodized silver & powder coated black, custom finished available
| NOMINAL SIZE GRAPHIC SIZE | OUTSIDE DIM. | VISIBLE AREA | CASE DEPTH | FRAME WIDTH |
| 16" x 20" | 16.75 x 20.75" | 15.5" x 19.5" | 3.5" | 0.625" |
| 20" x 24" | 20.75 x 24.75" | 19.5" x 23.5" | 3.5" | 0.625" |
| 20" x 30" | 20.75 x 30.75" | 19.5" x 29.5" | 3.5" | 0.625" |
| 22" x 28" | 22.75 x 28.75" | 21.5" x 27.5" | 3.5" | 0.625" |
| 24" x 24" | 24.75 x 24.75" | 23.5" x 23.5" | 3.5" | 0.625" |
| 24" x 30" | 24.75 x 30.75" | 23.5" x 29.5" | 3.5" | 0.625" |
| 24" x 36" | 24.75 x 36.75" | 23.5" x 35.5" | 3.5" | 0.625" |
| 24" x 48" | 24.75 x 48.75" | 23.5" x 47.5" | 3.5" | 0.625" |
| 24" x 60" | 24.75 x 60.75" | 23.5" x 59.5" | 3.5" | 0.625" |
| 30" x 30" | 30.75 x 30.75" | 29.5" x 29.5" | 3.5" | 0.625" |
| 30" x 40" | 30.75 x 40.75" | 29.5" x 39.5" | 3.5" | 0.625" |
| 36" x 36" | 36.75 x 36.75" | 35.5" x 35.5" | 3.5" | 0.625" |
| 36" x 48" | 36.75 x 48.75" | 35.5" x 47.5" | 3.5" | 0.625" |
| 36" x 60" | 36.75 x 60.75" | 35.5" x 59.5" | 3.5" | 0.625" |
| 36" x 72" | 36.75 x 72.75" | 35.5" x 71.5" | 3.5" | 0.625" |
| 36" x 84" | 36.75 x 84.75" | 35.5" x 83.5" | 3.5" | 0.625" |
| 36" x 96" | 36.75 x 96.75" | 35.5" x 95.5" | 3.5" | 0.625" |
| 40" x 60" | 40.75 x 60.75" | 39.5" x 59.5" | 3.5" | 0.625" |
| 48" x 48" | 48.75 x 48.75" | 47.5" x 47.5" | 3.5" | 0.625" |
| 48" x 72" | 48.75 x 72.75" | 47.5" x 71.5" | 3.5" | 0.625" |
