SMD5050 Light Strip RGB Series
1, Product names and codes
2, Light Source Parameter (Ta=25º C)
3, Electrical Performance
1) Working Voltage: DC12V
2) Power Consumption: 72W
3) Drive Mode: Constant drive
4) IF: 3600 mA
5) Max Peak Current: 6000mA
6) Electrostatic discharge: 2000V
7) Working Temperature: -40 ~ +50 º C
8) Storage Temperature: -50 ~ +60 º C
4, Connect Way
1) Wire Harness: 20AWG 100mmGray, White Electronic Wire / color transparent connect line
2) Standard Series Quantity: 5 M
3) Max Series Quantity for Simplex: ≤ 5M
5, Dimension
1) Housing Shell: Anti-static, No UV, ABS-B
2) Size(mm): 5000x10 / 5000x12 / 5000x14
3) Color of Waterproof Glue: Transparent
4) Color of PCB board: Milk white / Coppery Yellow
6, Mounting
1) Silica Gel: Can be chosen.
2) Gummed: 3M double-sided adhesive.
|
Products names |
Non-waterproof |
Waterproof |
|
Red |
MQ-RXT50R25-NF |
MQ-RXT50R25-TF |
|
MQ-RXT50R20-NF |
MQ-RXT50R20-TF |
|
Yellow |
MQ-RXT50Y85-NF |
MQ-RXT50Y85-TF |
|
MQ-RXT50Y92-NF |
MQ-RXT50Y92-TF |
|
Green |
MQ-RXT50G23-NF |
MQ-RXT50G23-TF |
|
Blue |
MQ-RXT50B23-NF |
MQ-RXT50B23-TF |
|
White |
MQ- RXT50WC35-NF |
MQ- RXT50WC35-TF |
|
MQ- RXT50WC65-NF |
MQ- RXT50WC65-TF |
|
MQ- RXT50WC10-NF |
MQ- RXT50WC10-TF |
|
MQ- RXT50WC16-NF |
MQ- RXT50WC16-TF |
|
LED Type |
5050 SMD |
|
LED QTY(1Reel=5000mm) |
300pcs/Reel ( 150pcs/Reel or 450pcs/Reel) |
|
Color |
Red |
Yellow |
Green |
Blue |
White |
Wavelength
(nm) |
625-
630 |
620-
625 |
580-
588 |
588-
595 |
520-
530 |
465-
470 |
3000-
5000 |
6000-
7000 |
9000-
10000 |
11000-
12000 |
Luminous
Intensity |
1560x
300 |
1560x
300 |
1580x
300 |
1580x
300 |
3800x
300 |
1200x
300 |
6000x
300 |
6000x
300 |
5800x
300 |
5800 x
300 |
Luminous
Flux(lm) |
1200 |
1200 |
1200 |
1200 |
1780 |
1050 |
3050 |
3050 |
3000 |
3000 |
|
View angle |
≥ 140° |
|
Life span |
50000H |
