Specification Sheet:
*. Code: M26-002
*. Name: Rigid strip-60-IP67
*. Base: 2PIN
*. Dimension: 1000*15*7mm
*. Weight: 130 g
*. Temperature: -40~70 Celsius degree
*. Body temperature: <53 Centigrade
*. Input: 12V AC/DC with reversed polarity protect
*. Output: 4.8w
*. Light quantity: 60
*. Light source: SMD
*. Light type: SMD
*. Beam angle: 120 degree
*. Color: Cool white, warm white, red, green, blue, yellow
*. Life span: 50000 hours
*. Assurance: CE, RoHS
*. Remark: IP67
Feature:
* Length: 1.0meter
* The colors of light resources can be warm white and cool white, the aluminum body can be black and silver
* 1.0m strip, 3PCS can be connected one by one at one time
* No dark space and with 120° View angle
* Accessories and connected wires with a perfect and humanistic way
* No ultraviolet and infrared radiation, low heat-release, long lifespan for 50, 000 hours
* Ways to fix: Fixed type and adjustable type
* The view angle can be rotated with 120 to light a large area, and the lights can be used in different places according to your detailed requirement
* Sealed way: Against dust with PVC and waterproof by silicone glue
* With CE and RoHS certificates
* High uniformity, pure color rendering and color quality for better visibility
Application:
* Architectural decorative lighting
* Archway, canopy & bridge edge lighting
* Amusement park, theater & aircraft cabin mood lighting
* Emergency hallway lighting
* Auditorium walkway lighting
* Stairway accent lighting
* Concealed lighting
* Backlighting for signage letters
* Channel letter lighting
* Cove lighting
* Furniture lighting
* Kitchen lighting
* Under-cabinet lighting/ Bar and freezer cabinets
* Display tray
Package:
@ Adopts imported high-grade environment riley long thick card as packaging material
@ Professional box lined design, the products are well protected in transit
@ Neutral screen
Type |
Color |
Size(mm) |
LED qty/meter |
Input Voltage |
Power/meter |
IP Class |
Lumen/meter |
RD3528-12-60-R |
RED |
1000*15*7 |
60pcs |
DC12V |
4.8W |
IP67 |
120 |
RD3528-12-60-Y |
YELLOW |
1000*15*7 |
60pcs |
DC12V |
4.8W |
IP67 |
120 |
RD3528-12-60-B |
BLUE |
1000*15*7 |
60pcs |
DC12V |
4.8W |
IP67 |
125 |
RD3528-12-60-G |
GREEN |
1000*15*7 |
60pcs |
DC12V |
4.8W |
IP67 |
240 |
RD3528-12-60-CW |
COOL WHITE |
1000*15*7 |
60pcs |
DC12V |
4.8W |
IP67 |
390 |
RD3528-12-60-WW |
WARM WHITE |
1000*15*7 |
60pcs |
DC12V |
4.8W |
IP67 |
360 |
RD3528-12-60-P |
PINK |
1000*15*7 |
60pcs |
DC12V |
4.8W |
IP67 |
120 |
