3HP Irreversible Protection Magnetic Starter 3 phaseApplicationTSE1-D Magnetic starter is mainly applied to circuit of AC 50 or 60Hz, voltage up to 550V for far distance making and breaking circuit and frequently starting and controlling motor. It has the features of small volume, light weight, low power consumption, high efficiency, safe and reliable perfornance etc.
Picures
![]()
![]()
Specification | Model | Rated
current(A) | Maximum power AC3 duty(KW) | Suitable
thermal
relay |
220V
230V | 380V
400V | 415V | 440V | 550V | 660V
690V |
| TSE1-D09 | 9 | 2.2 | 4 | 4 | 4 | 5.5 | 5.5 | TSR2-D1312
TSR2-D1314 |
| TSE1-D12 | 12 | 2 | 5.5 | 5.5 | 5.5 | 7.5 | 7.5 | TSR2-D1316 |
| TSE1-D18 | 18 | 4 | 7.5 | 9 | 9 | 10 | 10 | TSR2-D1321 |
| TSE1-D25 | 25 | 5.5 | 11 | 11 | 11 | 15 | 15 | TSR2-D1322
TSR2-D1353 |
| TSE1-D32 | 32 | 7.5 | 15 | 15 | 15 | 18.5 | 18.5 | TSR2-D2355 |
| TSE1-D40 | 40 | 11 | 18.5 | 22 | 22 | 22 | 30 | TSR2-D3353
TSR2-D3355 |
| TSE1-D50 | 50 | 15 | 22 | 25 | 30 | 30 | 33 | TSR2-D3357
TSR2-D3359 |
| TSE1-D65 | 65 | 18.5 | 30 | 37 | 37 | 37 | 37 | TSR2-D3361 |
| TSE1-D80 | 80 | 22 | 37 | 45 | 45 | 55 | 45 | TSR2-D3363
TSR2-D3365 |
| TSE1-D95 | 95 | 25 | 45 | 45 | 45 | 55 | 45 | TSR2-D3365 |
Standard control circuit voltage
| Volts | 24 | 42 | 48 | 110 | 220 | 230 | 240 | 380/400 | 400 | 415 | 440 |
| 50/60Hz | B7 | D7 | E7 | F7 | M7 | P7 | U7 | Q7 | V7 | N7 | R7 |
Dimensions(mm)
![]()
