FOXGOLDEN is one of the most impressing Hi-tech enterprises in China. We have specialized in this business line for 11 years.
Full Color LED Display Advantages:
Adopt imported high-quality LED chip (COTCO/CREE/AXT/SILAN/TAI WAN LED lamps) to manufacture full color LED display, with a large perspective, uniform color and immortality lights, low failure rate, easy to maintain etc...Standard products, production line, International quality, ultra-low prices.
1. Price Advantage of LED Display: Most competitive price for the same model in the market, at the same time, with the same or even better quality;
2. Performance Advantage of LED Displays: Good, even, higher conformity, large view angle, each single color lamp can be repaired;
3. Quality Advantage of LED Display: The whole process controllability from material to finished products, from R&D to production, becomes the guarantee of product quality dependability;
4. Service Advantage of Indoor Full Color LED Display: Much more sound service based on the same terms, and more deep cooperation based on the same service.
Trade terms:
1. Hardware: LED display and video controlling system
2. Technical material: English version user manual, installation manual and maintenance manual
3. Service:
Provide free technology support by phone and e-mail
7 years guarantee
4. Delivery: Approx 3-12 working days
5. Packing: Anti-shaking wooden package or Air Flight Case
6. Transportation: By sea or air or Express
Currently, FOXGOLDEN LED display is already exported to Asia, Europe, South America, North America, Africa and Middle East and other regions. We attained ISO9001: 2000, CCC. CE, FCC, RoHS etc.
For more details, please feel free to contact us. We will give you best service and timely reply.
| Description | Technical parameter |
| Unit module | Module size | 320*160mm |
| Pixel pitch | 20mm |
| Pixel density | 2500dots/m2 |
| Pixel configuration | 1R1G1B |
| Led specification | Φ 5ellipse |
| Pixel resolution | W: 16dots*H: 8dots |
| Cabinet | Dimension | 960mm*960mm*170mm |
| Quantities of module | 18pcs |
| Power supply | 4pcs |
| Thermal discharge | Fan*2pcs |
| Total weight | 55kg |
| Best viewing angle | 16-300m |
| Temperature | Storage: -35° C~+85° C |
| Working: -35° C~+85° C |
| Thickness | 17cm can adjustable |
| Remarks: cabinet size can changed, upon project need. |
| Power | Working voltage | AC220V/110V± 10% |
| Average power consumption | 250-500W |
| Max. Power consumption | ≤ 560W/sqm |
| Current | ≤ 20mA(single LED) |
| Control system | CPU | Pentium4 or above |
| Operating system | WIN98/2000/NT/XP |
| Control method | Synchronization |
| Main technical parameter | Driving device | Static scanning |
| Drive type | Constant Current driver IC |
| Refresh frequency | ≥ 400Hz |
| Grey scale/colors | 256 levels of each color(R/G/B)/16.7M color |
| Brightness of white balance | More than 8000cd/sqm |
| Brightness adjustment | 256 levels of each color(R/G/B)by software |
| Operating ambient humidity | 10%--95% |
| Video signal | PAL/NTSC |
| Control system | DVI display card+full color controller card |
| MTBF | ≥ 10, 000hours |
| Life span | ≥ 100, 000hours |
| Flatness | Tolerance of interpixel ≤ 0.3mm |
| Tolerance of modules clearance≤ 0.6mm |
| Power switch | Automatic switch |
| Display mode | 1024*768 |
| Communication distance | Unshielded twisted pair net line transmission distance 100m, max transmission distance 200m.
Multi-mode Optic fiber transmission distance 500m; Single-mode optic fiber transmission distance 10KM |
| Software | LED media player |
The company overview:
Foxgolden Group Ltd is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R & D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer ,FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness , but also makes breakthrough progresses on special usgaes. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and oveerseas market.
FOXGOLDEN provides a full series of LED display products involving various single and dual color , text & image display; indoor single & dual color , full color screen; outdoor single & dual color , full color display; dot matrix module display; traffic applied product;and series of indoor & outdoor module
With cultivation for high-quality production management team and project team , high quality products and local maintenance service; we only achieved 0.001% complaint in product quality for 7 constant years. that's why Foxgolden has received comprehensive attention form LED industrial experts these years!
Welcome to Foxgolden........
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
