Feature:
* Main cooling structure using anodized aluminum and atomization stripes PC, flame-retardant PC plug;
* LED panel lights and LED tube can be replaced;
* CRI above 80, finished luminous efficiency 100Lm / W;
* LED passed LM80 test, finished SCD <6;
*. Energy saved up to 50%, high intensity
*. 3-year life span
* CE certification
* No electric wave
*. No such hazard that mercury or lead enters the environment
*. No RF interference
Applications:
*. Shop display windows, restaurants, hotels and other indoor decoration lighting; Exhibition hall, art room, museum, office, reading the local lighting; Night bars, card access, etc. KTV atmosphere lighting; Jewelry, silver jewelry and Fashion lighting;
*. Local lighting: Corridor, bathroom, garage, parking-lot lighting, factories, security lighting of residential area, indicating lighting, etc. Realized the Green Energy-saving environmental protection.
| Specification | YL-MW18B-CE | YL-MW36N-CE | YL-MW40W-CE |
Watt(W) | 18 | 36 | 40 |
Lumens(lm) | 1850 | 3700 | 4100 |
Beam Angle(deg) | 120 | 120 | 120 |
CCT(K) | 2700~6500 | 2700~6500 | 2700~6500 |
CRI(Ra) | >80 | >80 | >80 |
Energy Efficiency Classes | A+ | A+ | A+ |
PF | ≥0.99 | ≥0.99 | ≥0.99 |
Efficiency Lm/W | 100 | 100 | 100 |
Voltage(V) | AC100-240 | AC100-240 | AC100-240 |
Frequency(Hz) | 50/60 | 50/60 | 50/60 |
Lifespan(hrs) | 25000 | 25000 | 25000 |
Working Temperature | -20~40 | -20~40 | -20~40 |
Storage Temperature | -20~85 | -20~85 | -20~85 |
Shenzhen Yili Electrical Co., Ltd. is a high speed development and innovative LED lighting enterprises, focused on development and quality management. The shift in position on the China manufacturing to China creative direction, depending on the China PRD complete LED industry chain, respectively in Taiwan, Shenzhen and Shanghai set up R & D and production base, the final formation of Taiwan R & D, complementary architecture Chinese assembly
Our company since its inception, zeroed in on the LED energy saving, environmental protection, safety, functional properties, long service life and use, designed to produce a series of LED lighting products (LED commercial lights, LED Panel Light, LED industrial panel light, LED Tube Light, LED T8 Tube, LED T5 Tube, LED high power panel light, LED tri-proof panel, LED indoor ceiling lights, LED strip panel), Widely used in Home Furnishing, commercial, office, hotel project and building decoration, advertisement decoration, bridge brighten, etc.
Our company has a modern production plant, advanced production equipment, perfect and reasonable flow of production. LED commercial lighting products company is committed to research and development of high quality, adhere to the "high quality", "professional", " innovation" the development direction, the main push products have their own multinomial patent and utility model patents certificate. With a strong R & D strength and perfect quality assurance system, after many years of product planning and marketing strategy layout, become to export LED export-oriented enterprises. All products have passed TUV GS, ETL, cETL, CE and RoHS safety standards, best-selling in Europe and the United States, and will continue to expand the market to the world.
