T600A LED High Bay Tube is designed for high lux requirement. Suggested mounting heights from 6m-15m
with primary applications including warehousing, commercial facilities, and manufacturing facilities.
Product Description:
T600A LED High Power Tube(High Bay) is designed for high lux requirement and narrow beam angle demands. Benefits include high efficiency, excellent color rendering, low glare, long life, dimming, and improved uniformity. Suggested mounting heights from 8m-15m with primary applications including warehousing, commercial facilities, manufacturing facilities, open and stack aisle applications.
Product Features:
？ High efficiency of 110lm/w
？ LG 5630, CRI85
？ High Quality Meanwell driver
？ PF>0.97, Flicker free at 100Hz (by camera)
？ Environmentally friendly, no mercury, No UV, No IR
？ IP65 waterproof and dust proof
？ Energy Efficiency Grade: A++
？ 5-year-warranty
Electrical and Technical Data
| Model No. | T600A0680W | T600A12150W | T600A15180W |
| Size: | 600x166x77 | 900x166x77 | 1500x166x77 |
| Lumen: | 9450-10000lm | 16500-17500lm | 20000-21000lm |
| LED QTY: | 192pcs | 360pcs | 448pcs |
| N.W: | 3.9kg | 6.8kg | 8.1kg |
| Input: | AC100-240V, 50/60Hz |
| CCT: | 4000K-4500K, 5000K-5500K |
| CRI: | CRI82-85 |
| Beam Angle: | 50° / 80° |
| Lifetime: | 50,000 hours |
| Temp.: | -20~50ºC |
| IP Grade: | IP65 |
| PF: | >0.97 |
| Dimming: | 1-10V, DALI, Microwave Sensor |
TG PHOTOELECTRIC TECHNOLOGY CO Ltd is a LED Lighting Division of SHENZHEN XINYUAO TECHNOLOGY CO Ltd which was founded in 2005 and evaluated as High-tech Enterprise by Shenzhen Municipal Science and Technology Commission.
TG has been committed to developing, manufacturing and marketing energy efficient LED lighting products including LED high bay/low bay lights, LED tubes, LED triproof lights and LED panel lights. Our experienced R&D team have continually launched new products with more optimized design and higher efficiency.
Strict and complete quality control system is implemented in the manufacturing processes to ensure all our products to be high level qualified. Our product certificates include CE, RoHS, TUV, SAA, C-Tick, UL, cUL and DLC.
