Features
1. Input voltage range: 85V~285VAC/47~63Hz
2. Constant current power supply with efficiency of 90%, and long life and high accuracy. Mean well Driver.
3. CREE XML chip up to 100lumens/w
4. Thermal conductivity brass heat sinks
5. Insulation rate: Class 1
6. International EMC Passed
7. Directives executed: IEC 60598, IEC 61000-3-2: 2005, IEC61347, UL8750
8. IP65
9. 5 Years Warrantyand.
|
Input Voltage Range |
85-285Vac |
|
Frequency Range |
47Hz~63Hz |
|
Inrush Current |
40A@ 220Vac Input; Cold start |
|
Power Factor |
0.95 |
|
LED Type |
Cree XML T6 |
|
The Q’ ty of led |
32 pcs |
|
Led Consumption |
184W |
|
Lamp Consumption |
210W |
|
Led Luminous Efficiency |
100Lm/W |
|
Led Initial Flux |
17000 Lm |
|
Color Temperature |
Detail information refer to above LED parameters table |
|
Color Rendering Index |
Ra> 75 |
|
Beam angle |
45° /90° /120° |
|
LED Junction Temperature @35degree |
75degree |
|
Working Temperature |
-20degree~+55degree |
|
Working Life-span 70% |
50000H |
|
Cable |
VDE H05RNF 3G0.75mm OR UL SJTW 3G16 AWG |
|
Led parameters |
|
|
|
Item |
Test condition |
Min |
Type |
Max |
Unit |
|
|
|
Power |
|
|
|
10 |
W |
|
|
|
Rated Current |
- |
- |
2 |
3 |
A |
|
|
|
Forward Voltage |
IF=2A |
3 |
3.2 |
3.4 |
V |
|
|
|
Color temperature |
Warm white |
IF=2A |
2700 |
3200 |
3900 |
K |
|
|
|
Pure White |
IF=2A |
4800 |
5000 |
5200 |
K |
|
|
|
Cool White |
IF=2A |
6000 |
6200 |
6500 |
K |
|
|
|
LED heat resistance |
|
- |
2 |
- |
Degree/W |
|
|
|
Junction Temp |
IF=2A |
- |
75 |
150 |
Degree |
|
|
|
luminous Efficiency @2A |
IF=2A |
80 |
100 |
120 |
(Lm/W) |
|
|
|
LED Chip Brand |
Cree XML T6 Class |
West Deer Technology Co., Limited is a skilled manufacturer and knowledgeable exporter of indoor and outdoor LED lighting fixtures. We have nearly 3 years of experience in the export business and we have grown into a highly efficient team, serving and providing our customers with an extensive range of high quality lighting fixtures at competitive prices.
West Deer Technology Co., Limited owns advanced production facilities and we have strong product development capabilities. Our corporate aim is "good quality and service and mutually beneficial cooperation". Our indoor line mainly produces LED tube lights, LED spotlights, LED global bulbs, LED ceiling lights, etc. Our outdoor line produces LED floodlights, LED streetlights and LED high bay lights Our lighting sources are always an imported brand name such as CREE, SemiLED, Bridgelux and Lumenmax, etc. All of our products are IEC and EMC standard qualified and CE, Rhos, C-tick FCC certified, some are UL certified as well.
West Deer Technology Co., Limited will work with our customers to establish a mutually beneficial relationship. We provide high quality products and an excellent service for partners from all over the world.
