Home LED Light Products LED Display Manufacture, LED Screen Manufacture, LED Display Factory

LED Display Manufacture, LED Screen Manufacture, LED Display Factory

LED Display Manufacture, LED Screen Manufacture, LED Display Factory
Price: US $ 1-1000/Piece
Trade Terms: FOB,EXW,CIF
Min Order: 5/Square Meter
Pay Type: L/C,T/T,Western Union
The most cost effective LED display for outdoor application, being introduced to the market for more than 10 years.
We have to say, for outdoor advertising, P20 & P16, are the most reliable products since ever!

Main Parameter

Category

Parameter

Pixel Pitch

20mm

Optimum Viewing Distance

20-50m

Density of Pixel

2500pixels/

Brightness

≥6500nite

≥7000nite

Module Resolution

16*16

LED Encapsulation

DIP346 2R1G1B

DIP346 1R1G1B

Driving Method

Virtual Static

Real Static

Optimum Viewing Angle

H: 110°V:50°

Module Size

320*320*27.7(mm)

320*320*33.4(mm)

Module Power

44w

50w

Module Weight

1100g

1200g

Cabinet Size

1280*960*178(mm)

1280*960*183(mm)

Cabinet Resolution

64*48

Cabinet Power

1320w

750w

Cabinet Weight

59kg

59kg

IP Rating

Front/Rear:IP65/IP43

Refresh Rate

1000-4000Hz( Different according to the different Driving IC )

Luminance Consumption

Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature25ºC.

MTBF

>5000hours

Defective Dot Rate

<0.0001

Life Span

>100000hours

Working Voltage

110-240 AC±10% 50-60Hz

Working Temperature/Humidity

-30ºC - +50ºC/10-90%RH

Storage Temperature/Humidity

-40ºC - +60ºC/10- 90%RH

Input Signal

RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc

Connector

CAT5 Cable(Length≤1430m),Optical link( Length≤20km,Optional)

Note: The above parameter is just for reference. Changes can be made according to customers' requirements





Prod Model: From P1 to P30
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Outdoor: IP65
Display Type: LED Video Display
Tube Chip Color: Full Color
IP Rating: IP65
Pixel Configuration: 1R, 1G, 1B
Certification: ETL
Pixel Pitch: 20mm
Display Function: Video Display
Application: Advertising
Scanning Mode: Static Scan
Average Power Consumption: 220W / m²
Pixel Density: 2500
Located in Baoan District, Shenzhen Myled Optech is an professional LED display manufacturer which is dedicated to LED display R&D; Production, sales, marketing and one stop solution for customers mainland and international. Myled provides consulting, installation, training and sales services for customers. We always regard customers as the company life line.

Shenzhen Myled Optech focus on indoor and outdoor full color LED display, LED curtain display, mesh, indoor and outdoor single and bicolor LED display manufacturing. We have established business relationship with customers in South America, Euro, and Asia etc. And win a good reputation among customers all over the world. And we provide full solution for Government, Telecom, Hotel, airport, bus station, stadium, and cinema and financial center, etc. Over the past years, we have finished some important LED display project for South American and China Mainland.

Quality is the most important theme for Myled and welcome to contact, and visit our company.

We hold the truth that better quality, better price and better sales services are our company culture.
