p6 outdoor advertising commercial led screen display advantage:
1) Wide viewing angle: The horizontal and vertical viewing angles are so wide that it is suitable for wide horizon.
2)Energy saving:low electric current,high-bright lamps,equipped with PFC switching power supply that save 30% electricty.
3) High refresh rate , high brightness and high contrast which make the screen without any delay and smear phenomenon under direct sunlight.
4)Environment protection, antistatic, dust-proof, good heat dissipation, cost-effective .
5) Error detection and monitoring:it can monitor the inner temperature,voltage,cooling fans etc and error detection automatically.
6) High reliability: using distributed scanning technology and module design technology that make higher reliability and stability.
7) Steady and reliable system:with strong anti-interference ability and long service life that can continually work for over 24 hours, and it's easy to operate the system.
8) Fast and easy installation, convenient maintenance of display modules.
P6 outdoor led screen p6 led panel P6 led display |
| Unit Module | Item | parameter |
| Model | P6 FULL Color Led Module |
| Module size | 192mm*96mm |
| Pixel Pitch | 6mm |
| Pixel Density | 27777dots/m2 |
| Pixel Configuration | 1R1G1B3 in 1 |
| Module Resolution | 32dots(W)*16dots(H) |
| Max power | 20w |
| Module Thickness | 2.7cm |
| Module Weight | 0.4kg |
| Driving Method | Constant Current Driving |
| Scan Method | 1/8scan |
| Interface Way | HUB75 |
| Brightness | ≥7000cd/m2 |
| Unit Module | Cabinet Size | 768mmx768mm |
| Cabinet Composing | 32pcs |
| Power supply Mode | 5V/40A 5V/60A |
| Cabinet Resolution | 128*128dots |
| Optimal Viewing Distance | 5M-50M |
| Optimal Viewing angle | 160°(W)120°(H) |
| Enviroment Temperature | Storage :-35ºC-+85ºC
work :-20ºC-+50ºC |
| Power | Relative Humidity | 10%-95% |
| Operating Voltage | AC220V±10% |
| Average power | 350W/H |
| Max power Consumption | ≤600W/m2 |
| Current | ≤20mA (Single LED ) |
| Control system | Computer | Pentium4 or above P4 or above |
| Operate system | WIN98/2000/NT/XP |
| Control Mode | Synchronization with PC |
| Main technical parameter | Driving Device | IC Constant current driving |
| Refresh Rate | ≥600HZ |
| Gray/Color | RGB each 256 grade, can display 16.7M clolor |
| MTBF | ≥9000hours |
| Power Switch | Automatic Switch |
| Display Mode | 800*600/1024*768/1024*900 |
| P6 Outdoor LED Screen from China factory |
Q: Where is your nearest Sea Port?
A: Our nearest sea port is at Xiamen,Fujian Provice
Q: What's the brand of your diode chip?
A: Our led lamps are by Sanan,Silan,Epistar,Cree etc.
Q: What is the led chip packing?
A:Indoor:SMD 3528/2121/1010 Outdoor:546 oval lamp/346 oval lamp/
Q:How to protect power supply?
A:Electrical peaks can put more force on the electrical components which will decrease life time .It is wise to install a protection (voltage stabilizer) that can control the peaks.
