Product Description:
(1)Multiplied file formats, such as AVI, MOV, MPG, DAT, VOB are comprehensive, and also we have three display mode as VGA+VIDE and VGA. There are also interfaces for Sound signal and video signal.
(2) 4096 grade grey control system and the color is over 16.7 millions, and the brightness, contrast, saturation, chroma can be adjusted by manual and sensor, whose scope is 256 grade.
(3) Show all kinds of word, text, graph, picture, video, 2-dimention, 3-dimention cartoon and other information with your PC does synchronously.
(4) Line-Double technology is adopted for the picture adjustment.
(5) Can be connected with PC and the web net and show the content, and also can be controlled remotely via VPM+ADSL.
(6) Can be used outdoor in all kinds of weather, and excellent capability of antisepsis, waterproof.
|
Pixel Pitch: |
12mm |
|
LED configuration : |
1R1G1B |
|
Brightness : |
7500 nits |
|
Pixel density : |
6944/sqm |
|
Viewing angle : |
110°H and 50°v |
|
Lifetime : |
60000 hrs |
|
Power consumption/tile : |
average 350w/m2, max 650w/m2 |
|
Operation power voltage : |
200-240 V / 50-60 HZ |
|
Tile/size (W×H×D) in mm : |
960×960×120 |
|
Tile/display surface in sqm : |
0.92 |
|
Cabinet Material: |
Steel |
|
Cabinet weight: |
60kg |
|
IP rating : |
IP65/54 |
|
Color : |
281 trillion |
|
Processing: |
16 bit |
|
Refresh rate : |
>2000HZ |
|
Max power cascade connection : |
5 cabinets |
|
Operating temperature : |
-15-40 degree |
|
Storage temperature: |
-20-60 degree |
|
Operation humidity: |
10-99% |
|
Storage humidity: |
10-90% |
