IP65 UL LED Wall Washer for Landscape Decorative

2016 New Wireless DMX512 72W 4 IN 1   1120mm  LED Wall Washer

Wireless Control Edison LED Wall Washer w/ Independent MODE and DMX Mode (Built-in Functions)

Aluminum Alloy
Ewin Lighting Tech address the Wireless Control LED Wall Washer. We are expecting you attention and High Level Involvement to Take a look!
Aluminum Alloy (Black/White Housing color available) w/ Rotary Angle: 150 Degree.


Application
Wireless Control LED Wall Washer Mainly used for Decorating and highlighting in Building Frame, Garden, etc which work in Independent mode and DMX mode;
1. Individual, historical buildings exterior lighting
2. Outside building and indoor local lighting
3. Landscape lighting, advertising lighting.
4. Health, culture and other specialized facilities lighting
5. Bars, dance halls and other entertainment atmosphere lighting

Color Changing Mode (RGB, Single Color, Available/Master Mode)
To Generate Various Color changing effects. Such AS 7 Colors Flashing/Fading/Chasing/Steady and 7 Color jumping Synchronously, Master/slave Mode color Changing effect.
256 Class gray degree dimmer, DMX Programmable w/ thousands of effects available if Many Lighting connected together

Control Mode 2 mode available
Independent Mode-Choose the color effects that you need by pressing the buttons on the side cap of light
DMX Mode-International Standard DMX512 Wireless Signal Control & 3XLR Signal Cable Control,

Tech Parameters
Input VOLT: 100-256V AC
Operating Voltage: 24V DC
IP Rating: IP65
Operating Temperature:  -20ºC~65ºC

Length(mm) available as follows Table


Model No	LED QTY	Color	Length(mm)	Power	Beam(°)
LWW-5-12P	12*1W	RGB/Single color	L440mm	12 Watts	15/30/45
LWW-5-12P	18*1W	RGB/Single color	L580mm	18 Watts	15/30/45
LWW-5-24P	24*1W	RGB/Single color	L840mm	24 Watts	15/30/45
LWW-5-36P	36*1W	RGB/Single color	L1120m	36 Watts	15/30/45
LWW-5-18*3W	18*3W	RGB/Single color	L1000mm	54 Watts	30/45/60
LWW-5-18*3W	18*3W	RGB (3IN1)	L1000mm	54 Watts	30/45/60



Features:

1. No need controller ,build-in DMX512 decoder

2. Simple installation , plug to AC220V only , no need wire to connect to DMX512 controller

3.Three working mode: independent, DMX, Master/Slave mode

4. Can be connect external DMX512 controller

5.High brightness, projecting up to 65 feet
6.Suitable for heavy duty (more than 12 hours per day)
7.High quality lens with 150°rotary angle, flexible to install

Description:







Best selling Points .
1. What is the Wireless system?


1. 7 Group ID Code can be set, The user can Use the Independent 7 groups of wireless network and won't mutually interference.
2. 7 Group ID Code corresponding to the color of the RGB indicator light, only the same ID lamps can communicate with each other.
2. ID code can be chosen by the button.
3. The indicator light kept lighting: No DMX or wireless signal.
4. LED red indicator light flashing: Signal sent
5. LED Green indicator Light flashing: Signal received.
6. Communication distance: 300 meters.
7. Working frequency ban: 2.4G, IM, 126 frequency Band.



Parameter for 1120mm LED Washer

Physical Specifications	(OEM/ODM: Available)
Dimension	L1120*W130*H82mm
Housing	Aluminum Alloy + Tempered Glass
Net weight	5.6 kg
Rotary Angle	150°
IP Rating	IP65(suitable for dry, wet, and damp environment)
Electrical Specifications
Lighting Source	4W LED
LED Quantity	18 pcs
Operation Temperature	-20°C~40°C(-4°F~104°F)
Input Voltage	100-256V AC
Power Consumption	72W
Optical Specification
Chip type	Edison
Beam Angle	15 ° ,25 ° ,30°,45°,60°,90°,30 °*60 °
Color	RGBW
1	60 meters
