Indoor P5 fixed front maintenance econmical led display
Our features and advantages:
1.High quality:
Use high quality LED with high luminous efficiency and low brightness decay to make the display stable.
2.Good effect:
To show vivid and clear pictures with high resolution, but low cost; Has good display effect in both pictures and letters because of using real pixel technology.The products support multiple display modes.
3.Easy maintenance:
Can fix the single point to save the maintenance cost.
4.Good uniformity:
Brightness difference within 10% between any two LEDs, to ensure the brightness and color uniformity of the display; Good uniformity in color solve the problem of mosaic well
5.Price
No. 1 cost effective. The price is very good, please contact us for an offer. You can compare and know!
Application Case:
Widely used for shopping malls, entertainment venues, schools, government agencies, trade fair, fair, aiming at the exhibition, press conference, meeting rooms, cinemas, airports, hotels, internal, station waiting area, indoorstadium, and a variety of public facilities and etc.
Our service:
1. Inquiry response time: within 24hrs.
2. OEM&ODM: design and produce your customized requirements.
3. Provide distributors customized design and models we already have.
4. Protect your sales area, design idea and all your private information.
5. Top quality + reasonable price+ patient after-sales service.
6. Mountain A-Li Group can also offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and LED large screen full color display
Trade Terms
1. Package: Anti-shaking wooden package, Air flight case or Carton package
2. Payment: T/T, 30% deposits before production, 70% balance to be paid before delivery
3. Shipping freight are quoted under your requests
4. Shipping port: Shenzhen, Mainland China
5. Warranty time: 2 years
6. Delivery time: 3-12 working days
Indoor P5 RGB LED Display Sign techincal parameters |
Unit Module | Item | parameter |
Model | ALS - P5 - 16S |
Module size | 320mm*160mm |
Pixel Pitch | 5mm |
Pixel Density | 40000dots/m2 |
Pixel Configuration | 1R1G1B |
Package mode | SMD3528 |
Module Resolution | 64dots(W)*32dots(H) |
Max power consumption | 25W |
Module Thickness | 14.27mm(without magnet) 26.6mm (with magnet ) |
Module Weight | 0.21kg |
Driving Method | Constant Current Driving |
Scan Method | 1/16scan / 1/8scan |
Interface Way | HUB75-A |
Brightness | ≥1600cd/m2 |
Unit Module | dimension | 640mmx640mm |
Quantity of Module | 16 |
Thermal discharge | fan 2pcs |
Power supply Mode | 5V/40A* 2pcs |
Pixel per cabinet | 128mm*128mm |
Thickness | 85mm |
Optimal Viewing Distance | 5M-30M |
Optimal Viewing angle | 160°(W)120°(H) |
Enviroment Temperature | Storage :-35ºC-+85ºC work :-20ºC-+50ºC |
Power | Relative Humidity | 10%-95% |
Operating Voltage | AC220V±10% |
Average power consumption | ≤1180W/m2 / ≤270W/m2 |
Max power Consumption | ≤500W/m2 / ≤800W/m2 |
Current | ≤20mA (Single LED ) |
Control system | CPU | Pentium4 or above P4 or above |
Operate system | WIN98/2000/NT/XP |
Control Mode | Synchronization with PC |
Main technical parameter | Driving Device | IC Constant current driving |
Refresh Rate | ≥400HZ |
Gray/Color | RGB each 256 grade, can display 16.7M clolor |
MTBF | ≥9000hours |
Power Switch | Automatic Switch |
Display Mode | 800*600/1024*768 |
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
