Indoor P3mm HD Rental LED Video Wall Display> CE, RoHS, FCC, ETL, CCC approved;
> Die-casting aluminum cabinet, 12kg/pc, high accuracy mechanical technology, flatness + - 0.1mm, make sure the whole screen flat and seamless;
> Absolute HD screen, smooth & exquisite image, good choice for stage background screen, giant TV, screen monitoring;
> SMD 3 in 1 pixel, black LED, wide viewing angle and better contrast for outstanding image;
> Small size cabinet unit, light body. Easy for shipping and installing;
> Low voltage module, easy for maintenance;
> Signal and power cable connectors makes all the cable connection easy, tidy and well-aligned. The whole screen is power safe. Naked installing is ok;
> Smooth, exquisite and vivid image. The display is of 10-bit colors, with 65536 gray scale to play natural and vivid image.
> Many mature controlling solutions are optional. 3G, 4G, WIFI, group cloud controlling are available. Camera, cable TV, the 2nd development docking with other devices and optional. There is always a solution suitable for situation needing;
> Top-Brand Components make sure the reliable quality, MW power supply, MBI driving IC, etc.
> All the PCB is covered by conformal coating. It is water proof & insulated in some extent and helpful for heat dissipation;
Applications, > Indoor Advertising - installed in kinds of shopping mall, super market, hotel, senior club, playing kinds of appointed ads, promotional information, etc. No matter it is video, flash, picture or text messages;
> Government & Enterprise Project - playing image promo, local cultures, landscape, etc.
> Culture & Tourism - playing information of landscape, interesting places, historic sites, local stories, culture, interesting manners and customs;
> Sport Matches - live broadcasting kinds of matches, events, posting the scores, etc.
> Image Propaganda - playing image promo, concerning ads, etc.;
> Commercial Real Estate - using as giant video wall to play concerning information comprehensively;
> Multimedia Meeting Room - installed as large multi-media video wall, playing the wanted video, pictures, etc. accordingly;
> Security & Protection - installed as giant monitor screen in central controlling room, monitoring all the situation of every camera real time.
> Kinds of Stage Show - used as stage background, playing requried background video, pictures, amazing lighting effects, etc.
Specifications, LED Specs |
LED Chip Brand | Red, Green, Blue: Epistar; |
Wave Length (nm) | R: 625nm; G: 525nm; B: 470nm |
Pixel Configuration | 1R 1G 1B |
Module & Cabinet Specs |
Pixel Pitch | 3mm |
Pixel Density | 111,111 Pixel/sqm |
Module Dimensions (W x H) | 192mm x 192mm |
Physics Pixel / Module | 64 x 64 pixels |
Module Frame | Integrated Lamp Board and Driving Board |
Cabinet Dimensions ( W x H xT) | 576 x 576 x 130mm |
Physics Pixel / Cabinet | 192 x 192 pixels |
Module QTY / cabinet | 9 pcs of module |
Cabinet Weight | 16 kg/pc |
Cabinet Material | Die Casting Aluminum Cabinet |
Cabinet Frame | Die Casting Aluminum Cabinet |
Tech. Parameters |
Brightness | 2000 cd/sqm, manual & auto adjustable |
Best Viewing Distance | 2 meters |
Power Consumption | Max. 1000 W/sqm; Average 300 W/sqm; |
Drive Mode | 1/32 scan, constant current driving |
Refresh Rate | >600 HZ |
Frame Rate | 60HZ |
Display Flatness | ±0.1mm |
Maintenance | Back access, replace the module or other components |
Led Life Span | 100,000 hours |
Supply Voltage | AC110V / 220V, 10% more or less |
Operating Temperature | -20 Celsius ~ +50 Celsius |
Operating Humidity | 10%-90% |
Storage Temperature | -40 Celsius ~ +60 Celsius |
Viewing Angle | Horizontal:120°; Vertical: 65° |
Grey Scale | Red, green, blue each 16k |
Display Colors | 4096 Billion |
Using Site | Indoor use, window use, no water proof |
Aging Time in Factory | More than 72 hours constantly |
Control |
System Supported | Win XP, Win Vista, Win7, Win8, Win8.1, Win10 |
Control Mode | Real Time Control (Synchronous) |
Display Capability | Flash, Video, Graphic, Text |
Signal Supported | RGB, VGA, DVI, etc. |
Warranty | 2 years |
Concerning Models |
HTF-RID2.5 | HTF-RID5 | HTF-ID6-S | HTF-RID4 | HTF-RID3 |
