Product Description
Our features and advantages:
1.High quality:
Use high quality LED with high luminous efficiency and low brightness decay to make the display stable.
2.Good effect:
To show vivid and clear pictures with high resolution, but low cost; Has good display effect in both pictures and letters because of using real pixel technology.The products support multiple display modes.
3.Easy maintenance:
Can fix the single point to save the maintenance cost.
4.Good uniformity:
Brightness difference within 10% between any two LEDs, to ensure the brightness and color uniformity of the display; Good uniformity in color solve the problem of mosaic well
5.Price
No. 1 cost effective. The price is very good, please contact us for an offer. You can compare and know!
| Indoor P3.91mm LED sign for rental led screen techincal parameters |
| Unit Module | Item | parameter |
| Model | ALS - P3.91 - 16S |
| Module size | 250mm*250mm |
| Pixel Pitch | 3.91mm |
| Pixel Density | 65536dots/m2 |
| Pixel Configuration | 1R1G1B |
| Package mode | SMD2121 |
| Module Resolution | 64dots(W)*64dots(H) |
| Max power consumption | 32w |
| Module Thickness | 14.66mm(without magnet) 26.55mm (with magnet ) |
| Module Weight | 0.573kg |
| Driving Method | Constant Current Driving |
| Scan Method | 1/16scan |
| Interface Way | HUB75E |
| Brightness | ≥1200cd/m2 |
| Unit Module | dimension | 500mmx500mm |
| Quantity of Module | 4 |
| Thermal discharge | fan 1pcs |
| Power supply Mode | 5V/60A* 1pcs |
| Pixel per cabinet | 128mm*128mm |
| Thickness | 65mm |
| Optimal Viewing Distance | 4M-10M |
| Optimal Viewing angle | 160°(W)120°(H) |
| Enviroment Temperature | Storage :-35ºC-+85ºC
work :-20ºC-+50ºC |
| Power | Relative Humidity | 20%-90% |
| Operating Voltage | AC220V±10% |
| Average power consumption | 168WH |
| Max power Consumption | ≤560W/m2 |
| Current | ≤20mA (Single LED ) |
| Control system | CPU | Pentium4 or above P4 or above |
| Operate system | WIN98/2000/NT/XP |
| Control Mode | Synchronization with PC |
| Main technical parameter | Driving Device | IC Constant current driving |
| Refresh Rate | ≥900HZ |
| Gray/Color | 4096 gray grade, can display 16.7M clolor |
| MTBF | ≥9000hours |
| Power Switch | Automatic Switch |
| Display Mode | 800*600/1024*768 |
| Indoor P3.91mm LED sign for rental led screen |
