Outdoor Waterproof P16 LED Video Wall Display board:
High quality outdoor waterproof p10 full color advertising led display screens
Outdoor P10 DIP Full Color LED Display Screen |
No. | Item | P16 |
1 | Pixel pitch | 16mm |
2 | Module size | 256mm*128mm |
3 | Module resolution(dots) | 16*8 |
4 | Pixel configuration | 1R1G1B |
5 | Pixel density | 3906dots/m² |
6 | Red wavelength | 625±2nm |
7 | Green wavelength | 525±2nm |
8 | Blue wavelength | 470±2nm |
9 | Colors | 16777216 |
10 | Best viewing distance | ≥15m |
11 | Horizontal view angle | 120° |
12 | Maximum power consumption | <550W/m² |
13 | Brightness | ≥8000cd/m² |
14 | Gray scale | 16 bits per color |
15 | Color temperature | 6500k |
16 | Control method | Synchronization&Asynchronization |
17 | Driving method | 1/4 scanning |
18 | Frame frequency | 60Hz |
19 | Refresh frequency | ≥1920Hz |
20 | Working voltage | AC220V/110V±10% |
21 | IP grade | IP 65 |
22 | Working temperature | -35°C~65°C |
23 | MTBF | >10,000 hours |
24 | Life span | >100,000 hours |
Product Description
Product Name:Waterproof P10 outdoor advertising LED display board
Why I recommend my customers to choose P10 outdoor Full color LED Display?Please browse four points as follows:
1.High Brightness:We are a professional factory which specialises in producting Outdoor Full color LED Display and LED Module, The Brightness is at least 8000cd/sq.M;
2.Waterproof:The Standard of LED Cabinet is IP65, which it can protect the rain and dust into the screen.You can fixed install the screen in the rainy day.
3.Wide Used in the outdoor:Widely used in Public,street advertising,shopping mall.Plaza station,Building billboard, expressway,ect
4.Energy Saving and Pro-Environment:Such as P10 outdoor Full color led display,100sq.M;If it is spent for 14hours/day,total 365 days/year.The Energy Saving led display will be save over 10,000 hours than traditional screen each year.
Company Information
FOXGOLDEN GROUP LTD (www.Foxgolden.Com)is a professional high quality LED display Manufacturer.We are speicficated in LED Display field for 11 years, and have already being the 7 years' Alibaba Golden Supplier.Since 2004, we have been dedicating to the aim that producing high quality products, and now FOXGOLDEN has been well integrated in terms of R&D, produce, project, capital and marketing.
Our service1. Your inquiry related to our products or price will be replied in 24hrs2. OEM, any your customized lightings we can help you to design and put into product3. Distributorship are offered for your unique design and our current models4. Protection of your sales area, ideas of design and all your private informationTrade Terms: Payment terms: | 35% deposit before production, 65% balance before shipping -T/T: -Paypal -Western Union -Escrow |
Packing: | -Standard Export Carton with fully Polyfoam or Pearl Wool -Flight case; -Anti-shaking wooden case |
Shipping: | LED module: 3 to 5 working days upon receiving deposit payment LED display: 5 to 8 working days upon receiving deposit payment |
After-Sales-Service: | -Lifetime with professional engineer support. -Within 1 year, supply spare parts for free if the machine has quality problem |
FAQQ1: When is the delivery time?A1: we will accomplish manufacturing within 10 days after receiving the deposit. Q2: What is the payment method?A2: We support a variety of payment methods, the most common is the TT. Q3: What's the pixel pitch for Outdoor LED Display Screen?A3: Outdoor (P6mm / P8mm/P10mm) Q4: Where is it used for?A4: Outdoor & rental use. Widely used for backdrop of staging event, rental business, live show, concert, etc. Q5: Can it play HD video?A5: Yes, it can realize HD video function with Linsn controlling system.Packaging & ShippingOur Services1. Guarantee(1) We guarantee all our displays, modules, parts for 2 - 5 full year. During this time, we will replace or remand our goods for free if there is something wrong with them.(2) We will provide maintenance for a lifetime and charge for the raw materials only.2. Technology Training(1) We provide the technology training for free, which contains the operation training and maintenance training in the factory.(2) We will send our engineers to your country by negotiation.3. Maintenance and Consultation(1) We provide full maintenance for a lifetime and charge for the raw materials only.(2) We also provide lifetime consultation by E-mail, call, MSN or other ways for free.4. Documents and Certification(1) We provide the operation manual, software, test report and so on.(2) We can also provide all kinds of certification such as CE, UL and so on.5. CAD Drawing and Fixing(1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.(2) We will send our engineers to your place if we are expected after our negotiation.6. Additional service(1) We provide you the forwarding information, and some other information such as flight box, structure information for your reference for free.Contact us: Andy Zhu - Project Manager please Feel free to contact with me!!!
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
