CreateLED indoor AirLED-5 series have robust die casting section and contrast ration comprised for both rental and permanent installations.
Main feature:
1. Ultra-light weight and slim design
2. Fanless design and front maintenance
3. Quick lock system allowing handling fast
4. Standard panel size 500mmx500mm making flexible assembling and dismantling
5. High refresh rate available for capture for DV&VCR
|
Model |
AirLED-5 |
|
Pixel Pitch |
5.2mm |
|
Unit Size |
500mmx500mmx65mm |
|
LED Type |
SMD 3-IN-1 |
|
Pixel / Unit |
96x96 |
|
Unit Weight |
7kg |
|
Viewing Angle |
H160 degree V100 degree |
|
Application |
Storage-40~60° C, Working-20~50° C |
|
Protection Level |
For indoor use only |
|
Power Consumption |
200W/panel Max |
|
80W/Panel Ave. |
|
Driving |
1/8 Scan |
|
Frame Refresh |
≥ 60Hz |
|
Data Refresh Rate |
600~2, 000Hz |
|
Processing |
16bit |
|
Max Brightness |
2, 000nits |
|
Power Supply |
AC90-240V, 50~60Hz |
|
MTBF |
≥ 1, 000 Hours |
|
Life Span |
≥ 50, 000 Hours |
|
Pixel Failure |
< 0.0003 |
Shenzhen CreateLED Electronics Co, . Ltd. Is one of the most professional LED Screen manufacturer to provide full solutions for fixed billboard market and rental market.
Especially since year of 2010 we explored and issued the innovative newly AirLED series for rental customers, standard solution for different applications, standard solution for ourselves mass production.
About outdoor fixed installation billboard, we are promoting the full viewing angle, complete water proof and lower power drive method outdoor cabinets, which is leading the trend of this billboard market.
Welcome to our Showroom and My Products for more detailed offer info.
