CreateLED indoor AirLED-7 series have robust precision extruded aluminum section and contrast ration comprised for both rental and permanent installations.
Main feature:
1. Ultra-light weight and slim design
2. Fanless design and front maintenance
3. Quick lock system allowing handling fast
4. Standard panel size 500mmx500mm making flexible assembling and dismantling
5. High refresh rate available for capture for DV&VCR
|
AirLED-7 |
|
|
Pixel Pitch |
7.8mm |
|
LED Type |
3-in-1 SMD |
|
Brightness |
1, 200nits-1, 500nits |
|
Viewing Angle |
H: 160 degree |
|
V: 100 degree |
|
Contrast Ratio |
2000: 1 |
|
Pixel Density |
16, 384/sqm |
|
1, 524/sqf |
|
4, 096/panel; 6, 144/panel |
|
Module Size |
250mm x 250mm |
|
Module Resolution |
32 x 32 |
|
Panel Size(WxHxD) |
500mmx500mmx65mm |
|
Panel Resolution |
64 x 64 |
|
Weight |
7kg/panel |
|
Power Consumption |
300W/Panel Max |
|
120W/Panel Ave |
|
Processing |
16 bit/color |
|
Refresh Rate |
1, 200-4, 000Hz |
|
Drive Method |
1/8 Scan Method |
|
Environment |
Indoor |
|
Max Stacking |
20 panels |
|
Max Hanging |
20 panels |
|
Servicing |
Front & Back |
|
Panel Material |
Precision Extruded Aluminum Section |
|
Source Compatibility(with Processor) |
VGA(RGBHV), DVI, HDMI, SDI(HDSDI) |
Shenzhen CreateLED Electronics Co, . Ltd. Is one of the most professional LED Screen manufacturer to provide full solutions for fixed billboard market and rental market.
Especially since year of 2010 we explored and issued the innovative newly AirLED series for rental customers, standard solution for different applications, standard solution for ourselves mass production.
About outdoor fixed installation billboard, we are promoting the full viewing angle, complete water proof and lower power drive method outdoor cabinets, which is leading the trend of this billboard market.
