Indoor Curtain LED Display (LS-IC-P15.625)
| Price: |
Negotiable/Square Meter |
| Trade Terms: |
FOB |
| Min Order: |
1/Square Meter |
| Pay Type: |
T/T |
Indoor Curtain LED Display P10 (LS-IC-P15.625):
Features of the Curtain LED Display:
**High resolution images
*Easily configured for various size and aspect ratios
*Wide viewing angle
*high brightness
*good heat dissipation
*easy maintenance
*Compatible with inputs: S-Video, Composite, YUV, RBG, SDI, HKSDI, Data SVI up to SXGA
Main Application: Stage and outdoor fixed installation
LEDSolution LED Display:
| Parameter | Unit | Value |
| Pitch | mm | 15.625 |
| Brightness | nits | 1, 000 |
| Color temperature | deg. K | 6, 500 |
| Viewing angle – Horizontal (50% brightness) | deg. | 120(-60~ +60) |
| Viewing angle – Vertical (50% brightness) | deg. | 120(-60~ +60) |
| Panel weight | kg | 8 |
| Panel width | mm | 1, 000 |
| Panel height | mm | 500 |
| Panel depth | mm | 105 |
| Panel area | sq. m. | 1.5 |
| Panel material |
| Epoxy paint coated Aluminum Strip |
| Operating temperature range | deg. C | -30 to +60 |
| Humidity operating | RH | 10% ~ 90% |
| Pixel type and configuration | R/G/B | 3in1 SMD |
| Resolution per panel |
| 64x32 |
| Dot per panel |
| 2, 048 |
| Dot per sq. meter |
| 4, 096 |
| LED per sq. meter |
| 4, 096 |
| Recommended minimum viewing distance | m | 12 |
| Drive Mode |
| Constant current drive |
| Colors |
| 1, 073.7 millions |
| Grey scale (linear) | Levels | 1, 024 levels per color |
| Brightness control | Levels | 100 |
| Contrast ratio |
| 1, 000: 1 |
| Processing depth | bit | 12 |
| Video frame rate | Hertz | 60 |
| Display refresh rate | Hertz | 180~3, 000 |
| Input voltage (nominal) | VAC | 110 to 240 |
| Input power frequency | Hertz | 50 to 60 |
| Input power (max) | Watts/ sq. m. | 300 |
| Input power (typical) | Watts/ sq. m. | 120 |
| Lifetime (50% brightness) | Hours | ≥ 100, 000 |
| Red wavelength (dominant) | nm | 620~625 |
| Green wavelength (dominant) | nm | 525~530 |
| Blue wavelength (dominant) | nm | 470~475 |
| Panel input format |
| DVI, MPG, AVI, WMV, RM etc. |
| Mounting System |
| Hanging/Fix Installation |
| Prod Model: |
LS-IC-P15.625 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brightness: |
1, 000nits |
| Viewing Angle: |
120/120 |
| Panel Size: |
1,000X500mm |
| Resolution Per Panel: |
64X32 |
| Panel Material: |
Epoxy Paint Coated Aluminum Strip |
| Drive Mode: |
Constant Current Drive |
| Mounting System: |
Hanging/Fix Installation |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Display Function: |
Video Display |
| Certification: |
ETL |
| Pixel Pitch: |
15.625 Mm |
| Pixel Density: |
4096DOT/M&Sup2 |
| Display Type: |
Windows7, Vista, XP, 2000, 98 |
