Our factory professionally manufacture follow products
1)single color LED display, dual color LED display, full color LED display.
2)indoor LED display semi-outdoor LED display and outdoor LED display.
3)LED moving sign, variable message signs, LED text display, programmable LED moving message sign board, LED scrolling message signs.
4)LED display screen, LED display board, LED display module, LED display control system.
5)LED video display, LED advertising display, truck mobile LED display, rental LED display, stadium LED display, concert LED display, stage LED display.
6)wireless control LED display board, computer controll LED display.
Main features:
Epistar and Silan brand LED chips, MBI5024 driver IC, Meanwell Power supply, all are famous brand materials
Vivid image and video, rich in describing the details of color
High brightness ≥ 1500 CD/m2, automatically brightness adjust to environment, IP65 and range working temperature design, can meet your indoor using request
Signal and power automatically timing function, automatically running
Remote control, error detection, control center management function, feedback the error by SMS
DOT-DOT correction function support
* Products function introduction:
1) High intensity and can be adjusted, so can meet the request of the customers according the application environment.
2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light
3) To pictures and character, have clear, exquisite and real display effect
4) Big viewing angle to 110 degree at horizontal line, 60 degree at vertical line, you can see at every angle at this range, no picture change, no color excursion
5) Can repair each LED lamps, so the cost of maintain is lower, and easy to repair.
* Products Advantages:
1) Price Advantage: We have the best competitive price at the market
2) Performance Advantage: Best Equality, high consistency, Big viewing angle, can repair each LED lamps
3) Quality advantage: From material to finished product, from design to produce, we control all steps, that's the guarantee of the quality and reliability.
4) Service advantage: Better service at same situation, better cooperation at same service!
* Products list and application area:
1) Full color LED display: Equally or compactly make the red, green, blue color in one DOT, equally distribute at the panel, so make the whole display
2) Usually apply for physical sports, advertisement, bank, stock exchange, station, port, marketplace, telecommunication, department, school, monitor, restaurant, entertainment
| Outdoor LED Display P10 SPECIFICATIONS: |
| Numbers | Technical indexes | Specification |
| 1 | Pixel pitch | 10mm |
| 2 | Module size | 160mm×160mm |
| 3 | Module resolution | 16×16 |
| 4 | Module density | 10,000dots/sqm |
| 5 | Pixel configuration | RGB |
| 6 | Red wavelength | 625±2nm |
| 7 | Green wavelength | 525±2nm |
| 8 | Blue wavelength | 470±2nm |
| 9 | Colors | 16777216 |
| 10 | Best viewing distance | 8m---150m |
| 11 | Horizontal viewing angle | 140° |
| 12 | Vertical viewing angle | 70° |
| 13 | Maximum power consumption | 1000W/sqm |
| 14 | Average power consumption | 335W/sqm |
| 15 | Brightness | ≥8000cd/m2 |
| 16 | Gray scale | 16bits of per color |
| 17 | Color temperature | 12000K |
| 18 | Driving method | 1/4scanning |
| 19 | Frame frequency | 60Hz |
| 20 | Refresh frequency | 300 Hz |
| 21 | Working voltage | AC220V/110V±10% |
| 22 | IP grade | IP67 |
| 23 | Working temperature | -20°C~80°C |
| 24 | MTBF | More than 10,000 hours |
| 25 | Life span | More than 100,000hours |
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
