Home LED Light Products High Resolution P4 Full Color Indoor LED Video Display

High Resolution P4 Full Color Indoor LED Video Display

High Resolution P4 Full Color Indoor LED Video Display
Price: US $ 650-700/Square Meter
Trade Terms: FOB,CFR,CIF
Min Order: 1/Square Meter
Pay Type: T/T,Western Union



We put into the market is the quality and reputation.








Some of the certificates

High Resolution P4 Full Color Indoor Video LED Display Features & Technology Specification:

1. Widely application field and short ROI time. Commercial advertising LED display screen, Stadium perimeter LED display screen, mobile trailer LED display, LED screen for mobile media, shopping mall LED display, screen for logo showing, LED display for bank or stock exchange rate showing, LED moving sign for train and bus station, LED display screen for air port, elecommunication LED display screen for information showing and instruction and ect.

2. Clear Vivid image quality displaying. Even in direct and full-on sunlight day to ensure you attract more audience to get short ROI of your LED display screen's investment.

3. Long term brightness. More than 6000 nits brightness for outdoor full color LED display, more than 800 nits brightness for indoor full color LED display capacity throught products lifetime of LED display screen.

4. Easy installation and programming. Easy and simple installation interface, use friendly software to ensure the user programme the LED display screen system.

5. Convenient servicing. Front and rear cabinet access makes maintenance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.

6. The list of availabe models of our LED display/screen/panels/signs. P4mm, P5mm, P6mm, P7.62mm, P10mm, P12mm, P16mm, P20mm, P25mm, and ect.


High Resolution P4 Full Color Indoor LED Video Display technical parameter :
Unit ModuleItemparameter
ModelALS - P4 - 16S
Module size256mm*128mm
Pixel Pitch4mm
Pixel Density62500dots/m2
Pixel Configuration1R1G1B
Package modeSMD2121/SMD 0508
Module Resolution64dots(W)*32dots(H)
Max power consumption18W
Module Thickness13.07mm(without magnet) 26.63mm (with magnet )
Module Weight0.18kg
Driving MethodConstant Current Driving
Scan Method1/16scan
Interface WayHUB75-A
Brightness≥1500cd/m2
Unit Moduledimension512mmx512mm
Quantity of Module16
Thermal dischargefan 2pcs
Power supply Mode5V/40A* 2pcs
Pixel per cabinet128mm*128mm
Thickness85mm
Optimal Viewing Distance4M-20M
Optimal Viewing angle160°(W)120°(H)
Enviroment TemperatureStorage :-35ºC-+85ºC
work :-20ºC-+50ºC
PowerRelative Humidity10%-95%
Operating VoltageAC220V±10%
Average power consumption85W/H
Max power Consumption≤160W/H
Current≤20mA (Single LED )
Control systemCPUPentium4 or above P4 or above
Operate systemWIN98/2000/NT/XP
Control ModeSynchronization with PC
Main technical parameterDriving DeviceIC Constant current driving
Refresh Rate≥400HZ
Gray/ColorRGB each 256 grade, can display 16.7M clolor
MTBF≥9000hours
Power SwitchAutomatic Switch
Display Mode800*600/1024*768
High Resolution P4 Full Color Indoor LED Video Display


Product Advantages :


1. Price Advantage: Best competitive price of the market.

2. Performance Advantage: Best brightness, High refresh rate, high consistency, big viewing angle etc .

3.Quality advantage: From material to finished product, from design to produce, we control all steps, which are the guarantee of the quality and reliability. we have the strictly 72hours old ageing test to ensure the quality of the products. 2 Years warranty . CE,ROHS,CCC, ISO9001 ,EMC ,FCC certificates .

4. Service advantage: With professional service team for 24 hours service! Rich advertising LED display engineering experience both in domestic and oversea market .


Trade terms :1. Payment:T/T,30% deposits before production,70% balance to be paid before delivery .
2. Shipping freight are quoted under your requests .
3. Shipping port: Shenzhen,mainland China .
4. MOQ:1SQM .
5.Package : Wooden packing and flight packing .
About Technology :1. We provide the technology training for free, which contains the operation training and maintenance training at our factory.
2. We will send our engineers to your country by negotiation.
3. We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
4. We will send our engineers to your place if we are expected after our negotiation.

OUR COMPANY offers user-friendly products that optimize productivity and business efficiency and maintain the highest standards of design and quality. Customer satisfaction is our prime objective and our high quality LED video display screen used in more than 140 countries and win a high reputation.


OUR COMPANY provides onsite product installation, debugging and maintenance service for our LED display. Such as:

1. After-sales service:

1) Service principles: Response in time, solve problems as soon as possible and ensure the use.

2) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges;
After Maintenance period, only charge the material costs fees free of manual work fees.

3) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.

4) Under normal use and storage, Our Company will be responsible for the equipments.


2. Pre-sales service:

1) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with client to find solutions.

2) Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection.


Prod Model: P4 indoor led display
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Module Size: 256mm*128mm
Pixel Resolution: 64dots(W)*32dots(H)
Max Power Consumpion: 18W
Module Weight: 0.18kg
Brightness Of White Balance: 1500CD/M2
Best Viewing Distance: 4m~22m
Mtbf: 9000hours
Cabinet Size: 512mmx512mm
Thickness: 85mm
Warranty: 2 Years
Tube Chip Color: Full Color
Display Function: Video Display
Pixel Pitch: 4mm
Pixel Configuration: 1R,1G,1B
Scanning Mode: 1/16 Scan
Display Type: LED Video Display
Application: Video
Certification: EMC/FCC/ISO9001
Pixel Density: 62500dots/M2
System Operating Platform: Win98/2000/Nt/XP
IP Rating: IP31
Shenzhen Mountain A-Li Group Electronic Technology Co., Ltd Major In LED Modules and LED Display. Indoor LED Display have P3 P4 P5 P6 P7.62 P10 (Have difference cabinets types ). Outdoor have P6 P7 P8 P10 P16 (Have difference cabinets types ), LED Modules have single color, double color and full color, LED Display Have Indoor LED display, Outdoor LED display, Outdoor LED screen. Indoor LED screen, LED video display, LED Video screen, LED Advertising screen, LED Advertising Screen.

Features:

1) With good lightening accordance and no mosaic

2) LED advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment

3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced

4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment

5) Uses real pixels rather than virtual pixels, better viewing effect

Applications:

LED advertising board wide applied in stadiums, advertising, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
