| Items | Parameter |
| Pixel pitch | 15.625mm |
| Led Chip | Cree/Nichia/Epistar |
| Pixel density | 4096dots/m2 (can replace traditional P16 type) |
| Pixel configuration | 1R1G1B |
| Maximum power consumption | 400W/m2 |
| Average power consumption | 200W/m2 |
| Weight | ≤18KGS/m2 |
| Brightness | ≥7000cd/m2 |
| Permeation rate | 35% |
| Unit Size | 1000mm(W)*500mm(H),thickness is 50mm |
| Viewing Angle | Horizontal: 120° Vertical: 60° |
| Protection Level | IP68/IP65 |
| Refresh Frequency | ≥1000Hz |
| Frame Rate | ≥60Hz |
| Working Temperature | (Work :-35ºC~+50ºC) |
| Relative Humidity | 10% ~ 90% |
| Grey Scale | Unique 14bit,True colors,Restore lifelike picture |
| Control Distance | Cat5 cable: 100m Single optical fiber: <10km |
| It can replace traditional P16 type | | | | | | | | | | | |
| It is the most light and slim type among the similar products | | | | | | | | | | | |
| High quality power supply,support wide voltage input range(100~240V AC) | | | | | | | | | | | |
| With power factor correction(PFC)+Synchronous rectification,Self-cooling design | | | | | | | | | | | |
| Without any additional auxiliary cooling equipment | | | | | | | | | | | |
| Low carbon environmental protection | | | | | | | | | | | |
| Stripe design,Slim and lightweight,Reduce drag,Good light transmission | | | | | | | | | | | |
| Aluminum alloy component,thickness is only 5cm,Lighter than conventional led display more than 60% | | | | | | | | | | | |
| Easy construction,front/rear maintenance,fast assembly and disassembly,single dismantle five seconds to complete | | | | | | | | | | | |
| Representing a decrease of 80% of the traditional display connector,reduce the failure rate,optical media for large wall screen project | | | | | | | | | | | |
Pre-sales service:
1) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual.If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users.Our company can ensure the consistence of completion time and contracted time.Any problems caused by natural factors or man-made, we will discuss with client to find solutions.
2) Our company can train the users based on the manual.The training include system use, system maintenance and equipment protection
3) Support prints your logo on products and let your logo shine anywhere.OEM/ODM orders are warmly welcome.
Shenzhen Mountain A-Li Group Electronic Technology Co., Ltd Major In LED Modules and LED Display. Indoor LED Display have P3 P4 P5 P6 P7.62 P10 (Have difference cabinets types ). Outdoor have P6 P7 P8 P10 P16 (Have difference cabinets types ), LED Modules have single color, double color and full color, LED Display Have Indoor LED display, Outdoor LED display, Outdoor LED screen. Indoor LED screen, LED video display, LED Video screen, LED Advertising screen, LED Advertising Screen.
Features:
1) With good lightening accordance and no mosaic
2) LED advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment
3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced
4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment
5) Uses real pixels rather than virtual pixels, better viewing effect
Applications:
LED advertising board wide applied in stadiums, advertising, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
