Quick Details
Light Source: LED
Item Type: Light Strips
LED Light Source: LED
Type: Flex LED Strips
Input Voltage(V): DC5v
Lamp Power: 55w
Working Temperature(ºC): -20 - 50
Working Lifetime(Hour): 50000
Certification: CE, RoHS
Emitting Color: Changeable, RGB
Place of Origin: Guangdong, China (Mainland)
Brand Name: LF
Model Number: L-FW5050RGB18PF-8806-5V
IC type: LPD6806 LED digital strip lights
Led/m: 36
IC/m: 18
Voltage(DC): 5v
Grey Grade: 128
Image Pixel: 36
Waterproof Grade: IP65
Max Power: 11w
LED Chip: Epistar
Packaging & Delivery
Packaging Details: | Plastic packaging, anti-static, carton box |
---|
Delivery Detail: | 7~10 after confirm the order |
---|
Quick Details
LPD6803 digital led strip lights 5050 RGB
Place of Origin: Guangdong China (Mainland) | Brand Name: LF | Model Number: LF-FW5050RGB18PF-8806-5v |
Name: LPD6803 digital strip | Input Voltage: DC 5V | MAX Power: 11W/M |
Life: 50,000h | SMD: 5050 | IC Quantity:18 /M |
PCB color: brown/white | Color: RGB | LED Quantity:36LEDs/M |
Viewing angle: 120 | Certificate: CE, ROHS | Controller:LF-1212SDV2 |
Packaging & Delivery
LPD6803 digital strip lights 5050 RGB
Packaging Detail: Plastic packaging, anti-static, carton box
Delivery Detail: 7~10 working days after confirm the order
Specifications
Technical Data:CL-FW5050RGB15PF-6803
Part number | Data |
Input voltage | DC 5V |
Max Power/M | 11W |
Beam angle | 120 degree |
Life span | 50.000 |
Working temperature | -20°c~ +50° |
Storage Temperature | -30~ +65° |
IP Degree | IP65 |
Frequency | 50-60HZ |
Humidity | <85% |
Power factory | >93% |
Grey Grade | 256 |
Dimensions(mm) | 5000mm*14mm*4mm 5M/Ree |
IC QTY | 18/M |
LED QTY | 36LEDs/meter |
Installation
It has a 3M self-adhesive backing so is easily applied to most smooth surfaces by simply removing the backing paper.
1) Clean the surface where you plan to attach the flexible strip light, Ensure there is no dust or oily material on the sticking space.
2) Peel off the 3M tape from the backside of the ribbon.
Place the strips on the contour and slightly press the front of the strip, so the strip can firmly attach on the surface.
