Home LED Light Products High Definition P8 Outdoor SMD RGB LED Display

High Definition P8 Outdoor SMD RGB LED Display

High Definition P8 Outdoor SMD RGB LED Display
Price: US $ 675-677/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 2/Piece
Pay Type: L/C,T/T
P8 SMD Outdoor Full Color LED Display

1. Large viewing angle
2. Light weight
3, ISO9001,CE , CCC,ROHS Certificates
4.Long lifespan
5.High brightness


Specification


The specifications of modules
ItemsParameter
Product ModelP8 Full Color Led Module
Module size256mm*128mm
Pixel pitch8mm
Pixel density15625dots/m2
Pixel configuration1R1G1B
Module resolution32dots(W)*16dots
Module maximum power consumption25W
Module Thickness25CM
Module Weight0.55kg
Driving methodConstant Current Driving
Scanning method1/4 scan
InterfaceHUB75
Brightness≥6000-6200cd/m2
The specifications of cabinets
Cabinet size1024mm*768mm
Module quantity24pcs
Power supply5V/40A 5V/60A
Cabinet resolution120*120dots
Optimal viewing distance8M~100M
Optimal viewing angle160°(W) 120°(H)
RHWorking temperature(Work :-20°C~+60°C)
System operating humility10%-95%
The specifications of power supplier
Operating VoltageAC220V±10%
Average power consumption380W/H
Maximum power consumption≤760W/m2
Electric current≤20mA(single LED)
The specifications of control card
Control PanelsPentium4 or above
Operating systemWIN98/2000/NT/XP
Control modelSynchronization with PC
The specifications of the main technical parameters
Driving deviceConstant Current Driving
Refresh rate≥600HZ
Grey scaleRGB Each 256, can display 16.7M colors)
MTBF≥9000hours
Power switchAutomatic Switch
Display Mode800*600/1024*768/1280*900


Our service

1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM&ODM, any your customized lightings we can help you to design and put into product
3. Distributorship are offered for your unique design and some our current models
4. Protection of your sales area, ideas of design and all your private information
5. Top quality+Reasonable price+Responsible After Service=Successful & Win
6. Chipshow can offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and led large screen full color display.


Trade Terms

1. Package: Anti-shaking wooden package, Air flight case or Carton package
2. Payment: T/T, 40% deposits before production, 60% balance to be paid before delivery
3. Shipping freight are quoted under your requests
4. Shipping port: Xiamen, China
5. Warranty time: 1years
6. Delivery time: 3-12 working days





Prod Model: P8
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Module Size: 256mm*128mm
Cabinet Size: 1024mm*768mm
Brightness: 6200CD
Tube Chip Color: Full Color
IP Rating: IP65
Pixel Configuration: 1R, 1G, 1B
Display Function: Video Display
Average Power Consumption: 350W / m²
Scanning Mode: 1/4 Scan
Display Type: LED Video Display
Application: Advertising
Certification: CCC
Pixel Pitch: 8
Pixel Density: 15625
Quanzhou Jiacai Electronics Co., Ltd is a hi-tech company which is located in Fujian Quanzhou. Our factory is founded in 2006, coving an area of 175000 squar meters, with 35PCS producton lines for out door DIP modules, 6PCS production lines for indoor SMD products and more than 1600 skilled workers

Our RD team is composed by experienced experts, specialists and engineers, we can keep pace with the development of new technology and are able to provide creative products to meet different requests of our clients.

Our main products include indoor LED display, outdoor LED display, LED module, LED panel, rental and creative LED Solutions for various applications including sport, advertisement, concert, shopping mall, stadium, exhibition or any other indoor and outdoor events. All our products have passed CE, FCC and RoHS certificates. We are an LED company you can count on for good quality and competitive pricing. Besides, you can also expect excellent pre-sale, selling and after-sale services here, which contains professional consultation, free training, free drawings, installation and 1 years warranty

We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
