HD P2.0 indoor full color led display with die-casting aluminum cabinet size of 400x300mm,high contrast,high gray scale with MBI5153 driving IC, no strobe and flash
1.SMT led encapsulation ensure the wide view angle and high brightness
2.Combined driving PCB Board confirm the slim module,low power consumption
3.Black body led lamps confirm the high brightness,high contrast rate
4.Die-cast Aluminum material,keep strong configuration and good heat dissipation
5.Small panel size of 400×300mm and with thickness of 60mm only, lighe weight, can be taken by hands
6.Packed with flight case,easy to collect and can move to anywhere
7.With fast locks and aviation plugs,easy to install and dismantle,better for rental
8.Seamless splicing,good performance,smooth surface like a tv screen
This cabinet size also suit to Indoor led display P1.56,P1.66,P1.923,P2.0,P2.5,popular used in meeting room, conference, show ,monitor centre etc.
Indoor P2.0 Full Color LED Display Main Parameters |
| Visual Characteristics | Unit | Value |
| Pixel Pitch | mm | 2.0 |
| Pixel Density | Dots/sq.m | 250000 |
| Pixel Configuration |
| Black body SMD1010 |
| Cabinet Resolution | dots | 240×240 |
| Refresh Rate | Hz | ≥1920 |
| View Angle(H/V) | ° | 150/120 |
| Brightness | nits | ≥1500 |
| Gray Scale | Bit | 16 |
| IP Rating |
| 31 |
| Power Consumption(Max/Avg) | W/sq.m | 1200/500 |
| Input Voltage(AC) | V | 110~240 |
| Modular Characteristics |
| Cabinet Size(W×H×D) | mm | 400×300 |
| Cabinet Material |
| Die-casting Aluminum |
| Cabinet Weight | Kg | 6.0 |
| Module Size(W×H) | mm | 200×300 |
| Environment |
| Operation Temperature | ºC | -20~+50 |
| Operating Humidity |
| 10%~90% |
| Driving Mode |
| 1/30 Scan |
| Control Distance | Cat 5E <100m,Single mode fiber<10Km |
PRT OPTOELECTRONIC Co., Ltd is located in Bao'an District of Shenzhen city, specializing in R&D, manufacturing LED display screen and some related LED lighting, owned several new-automatic production lines and advanced test equipments to control quality. And got the international standard certificates of ISO9001-2000 and 14001, CE, CCC, FCC, RoHS.
Our main products include full color LED display, Outdoor LED display, Indoor LED display, Rental LED screen, Stage LED curtain screen, Sport stadium LED screen, Mobile LED screen etc. Also supply LED professional stage light, LED decoration lights, LED panel light, based on some customer' s request.
Our subcompany named PRT International Trade Co., Ltd, who in charge of exporting business, members with rich exporting experience over ten years, guarantee the products to be shipped out smoothly, so we can provide our clients high quality products with competitive prices and excellent service, and obtained a good reputation from our customers.
Our company's operating philosophy, "Quality is everything, Service is the key to success ", because our purpose is to let business done easily and trustingly, to save customer's searching time and purchase cost, solve problem on customer's position, to let everything to be "PERFECT"(abbreviated to"PRT" )!
PRT is a developing company, need hard work of our staffs, also need your large positive support, let us do business and develop together, "sincere cooperation, mutual benefit and common development" is our principle.
You are welcome! Waiting for you!
